ADI_PWR_SSEL_13
ADI_PWR_SSEL_14
ADI_PWR_SSEL_15

ADI_PWR_VDDEXT

This data type defines the external voltage (
regulator.
ADI_PWR_VDDEXT_330
ADI_PWR_VDDEXT_250

ADI_PWR_VLEV

This data type defines the acceptable voltage levels for the voltage regula-
tor. The values for ADSP-BF533 and ADSP-BF561 processors are:
ADI_PWR_VLEV_085
ADI_PWR_VLEV_090
ADI_PWR_VLEV_095
ADI_PWR_VLEV_100
ADI_PWR_VLEV_105
ADI_PWR_VLEV_110
ADI_PWR_VLEV_115
ADI_PWR_VLEV_120
ADI_PWR_VLEV_125
ADI_PWR_VLEV_130
ADI_PWR_VLEV_135
ADI_PWR_VLEV_140
VisualDSP++ 5.0 Device Drivers and System
Services Manual for Blackfin Processors
Power Management Module
Divides voltage core oscillator frequency by 13.
Divides voltage core oscillator frequency by 14.
Divides voltage core oscillator frequency by 15.
) supplied to the voltage
VDDEXT
3.3 V
2.5 V
0.85 V
0.90 V
0.95 V
1.00 V
1.05 V
1.10 V
1.15 V
1.20 V (default)
1.25 V
1.30 V
1.35 V
1.40 V
3-53
