1
Open a standard Web-browsing application such as Microsoft™ Internet Explorer™
(Version 6.0 and higher) or Netscape™ Navigator™ (Version 7.0 and higher).
2
In the Uniform Resource Locator (URL) field, specify the IP address of the VCX V7122
(e.g., http://10.1.10.10); the Embedded Web Server's 'Enter Network Password' screen
appears, shown in
Figure 16
Embedded Web Server Login Screen
3
In the 'User Name' and 'Password' fields, enter the username (default: "Admin") and
password (default: "Admin"). Note that the username and password are case-sensitive.
4
Click the OK button; the 'Quick Setup' screen is accessed (see

Using Internet Explorer to Access the Embedded Web Server

Internet Explorer's security settings may block access to the gateway's Web browser if
they're configured incorrectly. In this case, the following message is displayed:
Correct authorization is required for this area. Either your browser does not perform
authorization or your authorization has failed. RomPager server.
To troubleshoot blocked access to Internet Explorer, follow these steps:
1
Delete all cookies from the Temporary Internet files. If this does not clear up the problem,
the security settings may need to be altered (see Step 2).
2 In Internet Explorer, Tools, Internet Options select the Security tab, and then select
Custom Level. Scroll down until the Logon options are displayed and change the setting
to Prompt for username and password and then restart the browser. This fixes any
issues related to domain use logon policy.

Getting Acquainted with the Web Interface

Figure 17 shows the general layout of the Web Interface screen.
3Com VCX V7122 SIP VoIP Gateway User Manual
Figure 16.
Unauthorized
Figure 15 on page 38).
43
