ExtremeWare XOS 11.5 supports only the Summit X450 family of switches and the BlackDiamond 8800 series switch.

configure traffic ingress queue add egress queue

configure traffic ingress queue <queue_name> add egress queue <equeue_name>
ports [all | <port_list>]
Description
Using HQoS, associates the egress queue and egress ports to the ingress queue and specifies the egress
interfaces. The set of egress ports may be different for every ingress queue to which the egress queue is
added.
Syntax Description
queue_name
equeue_name
all
port_list
Default
N/A.
Usage Guidelines
NOTE
The egress traffic queue is applied to ports only.
You must have configured the HQoS ingress and egress queues prior to using this command to
associate the egress queue with an ingress queue. Also, you must have configured the ingress queue to
allow egress shaping prior issuing this command. If you issue this command using an ingress-only
queue, the command fails, and the system returns the following message:
No egress shaping allowed on this ingress queue
You associate one egress queue with different ingress queues by re-issuing this command and
specifying different ports.
Traffic from the ingress queue that flows to egress ports other than those specified in the egress queue is
unlimited on egress.
ExtremeWare XOS 11.5 Command Reference Guide
Enter the ingress traffic queue you are associating with the specified egress
queue.
Enter the egress queue you are associating with the specified ingress queue.
Specifies all egress ports are associated with the specified association between
this ingress queue and this egress queue.
Enter the egress port numbers you want associated with the specified
association between this ingress queue and this egress queue.
configure traffic ingress queue add egress queue
