Element
AdjacentSpaceId
RectangularGeometry
PlanarGeometry
CADObjectId
Sample:
- <Surface id="su-1" surfaceType="ExteriorWall">
<Name>S-101-E-W-1</Name>
<AdjacentSpaceId spaceIdRef="sp-1-Room" />
+ <RectangularGeometry>
+ <PlanarGeometry>
+ <Opening id="su-1-op-1" openingType="NonSlidingDoor" constructionIdRef="con-sample-3">
<CADObjectId>223528</CADObjectId>
</Surface>

Opening Element

Supported Attributes:
Attribute
id
Name
Description
This is the Id for a space that is bounded by this surface.
See Opening Element
See Opening Element
Surface and Opening elements get an CADObjectId element assigned according ot the
below described schema, based on associative room bounding.
(Family Name): (Family Type)(Element Id)
Sample:
Basic Wall: Cast Concrete Wall 12" [49749]
Description
This attribute is a hyphen-separated string, consisting of a prefix, op and a sequential number.
For example, op-1.
Surface and Opening elements get an Name element assigned according to the below described
schema:
(Orientation)-(Space#)[-(Other space#)]-(Exposure)-(Type)-(sequence number) [Opening Type+#]
Sample:
N-101-102-E-W-D-84
N = Orientation [N/NE/E/SE/S/SW/W/NW/N/T/B/X]
(every surface within the sector of 22.5 degrees from the north vector gets the letter N etc) (hori-
zontal surfaces facing upwards get the letter T for top, downwards B for bottom) (shading surfaces
get the letter X for differentiation)
101 = Space number
102 = Other space number
E = Exposure - exterior/interior/underground [E/I/U]
W = Type [W/C/R/F] (Wall, Roof, Ceiling, Floor, Shade) (every surface type has it's letter W-Wall
R-Roof C-Ceiling F-Floor S-Shade)
O = Opening Type [W/D/O] (Window, Door, Opening) (every opening type has it's letter W-
Window D-Door O-Opening)
77 = sequence number
Sample surface names:
