COBHAM Satcom EXPLORER 540 User & Integrator's Manual page 97

4.13.5 SIM PIN for cellular network
See Optional: To set up cellular network for data (dual mode) on page 4-49.
4.13.6 To save or load a configuration
If you need to reuse a configuration in other terminals of the same type, you can save
your current configuration to a file, which can then be loaded into the other
terminal(s).
Note
To save a configuration to a file
To save the current configuration of your EXPLORER 540 to a file on your computer, do
as follows:
1. In the Advanced page, click Load/save configuration.
2. Click Save configuration.
The configuration file is saved in the EXPLORER 540.
3. Click Download configuration...
The configuration is downloaded from the EXPLORER 540 to the downloads section
of your computer.
To load a configuration from a file
To load a configuration from a file into your EXPLORER 540, do as follows:
1. In the Advanced page, click Load/save configuration.
2. Click Load configuration.
3. Browse to the configuration file and click Open.
The configuration is now loaded into your EXPLORER 540. When the configuration is
loaded successfully, the EXPLORER 540 restarts with the new configuration.
98-148232-K
Be aware that if the terminals have different software versions, some of the
settings may be different than expected. If possible, use the same software
version in the terminals.
Chapter 4: Configuration with web interface
Advanced settings
4-33
