Icons in the icon bars
The icon bars are always available at the top and bottom of the web interface. Some of
the icons are permanent while others are temporary.
Icon






To navigate the web interface
• To access status and settings, tap or click the relevant icon in the icon bar or select

to access the Control panel. The status or settings are displayed in the contents
section.
• To see your current location and to move back through the Control Panel
menu, use the breadcrumbs just below the icon bar.
• To scroll through longer pages, use the scroll bar or swipe.
• To refresh the current page, press Ctrl+F5 (PC) or Apple+R (Apple) or Cmd+R
(Apple).
98-148232-K
Signal level of the external network (BGAN).
Signal level of the external network (Cellular).
Help. Click to get context-sensitive help for the current
page.
Control panel. Click to access the settings.
Dashboard page where you can start and stop data
connections. Click to go to the Dashboard page.
The "1" at the icon shows that a BGAN data connection
package is running.
Status. If the screen is not large enough to show the
status field, this icon appears at the bottom of the page.
Click the icon to see status of the terminal and satellite
connection. Click again to exit the status page.
An alert is active.
Click the icon to see a list of active alerts.
Note that this icon will remain in the icon bar as long as
the alert is still active.
Chapter 4: Configuration with web interface
Explanation
