COBHAM SAILOR 150 Quick Manual

SAILOR 150 FleetBroadband
Quick Guide

Make a voice call

To make a call from your SAILOR FleetBroadband
terminal, dial
00 <country code> <phone number> #
Example: Cobham SATCOM in Denmark:
00 45 39558800 #
Note: There are two audio qualities for voice:
Standard voice and 3.1 kHz Audio. The default
audio quality is Standard voice.
To force the call to use Standard voice, dial 1 *
before the number.
To force the call to use 3.1 kHz Audio, dial 2 *
before the number.
To make a call to the terminal, dial
+<mobile number>
Note: There are two mobile numbers for voice,
one for 3.1 kHz Audio and one for Standard
voice.

Send a fax

To send a fax from the terminal, dial
00 <country code> <phone number> #
Example: Cobham SATCOM in Denmark:
00 45 39558888 #
Note: For an analog fax, the audio quality must
be set to 3.1 kHz Audio.
To force 3.1 kHz Audio, dial 2 * before the
number.
To send a fax to the terminal, dial
+<3.1 kHz Audio mobile number>
Alternatively you can send a fax directly from
your PC using an electronic fax application.

Make a local call

To make local calls between phones connected
to the same terminal, do as follows:
• For a local call to an IP handset, dial the
number of the IP handset (e.g. 0501) followed
b
by # or .
• For a local call to an analog phone, dial 0301
followed by # or b
For information on allocation of local numbers,
refer to the User Manual.

Access the Internet

To access the Internet do as follows:
1. Connect the LAN cable between your
computer and the FleetBroadband terminal.
2. Start up your computer.
3. Open your browser.
If your data connection is automatically enabled,
you should now have access to the Internet. If
not, you must start a connection as described in
the next section.
.
