Power control pin is active: The terminal is on and will stay on as long as the pin is
active.
Power control pin is inactive: The terminal will go into power save state when the
Idle time has expired and none of the configured wake-up methods are active. See also
the note in the previous page.
3.6.4 To set up power save functions with AT commands
For details on how to use AT commands see To access the terminal using AT commands
on page 3-3.
You can set up the following power save functions with AT commands:
• Remote on/off
• Idle time with Daily wake-up and/or Wake-on-LAN
Remote on/off
With the AT command AT_ITREMONOFF you can set up
• Enable or disable the Remote on/off function
• Shut down delay after the Power control pin is deactivated
• Daily awake period (time of day and duration)
• Polarity of the Power control pin (active high or low)
Important
Set up the Remote on/off function as follows:
1. Type in the AT command:
AT_ITREMONOFF=<active mode>,<power down delay>,<awake time of
day>,<awake duration>,<polarity>
Example: AT_ITREMONOFF=1,3,60,10,HIGH
In the example above, Remote on/off is activated (1) with 3 minutes shut down
delay (3), awake time of day 60 minutes after midnight (60), 10 minutes duration of
awake time (10) and Power control pin active high (HIGH).
Note
Note
98-148232-K
Before configuring the remote on/off function, connect the Power
control pin as described in Connection example for the Power control pin
on page 3-20.
If you set Awake time of day to 0, the daily awake period is disabled.
Changing <active mode> from 1 to 0 will change the power mode from
Remote on/off to Always on.
Changing <active mode> from 0 to 1 will change the power mode to Remote
on/off.
