• IP address: The external IP address that has been assigned by the service provider
to this session. If the connection was started by remote SMS, the local IP address is
also shown.
• Transferred data: For Standard data, the tile shows the total amount of transmitted
and received data since the connection was established.
4.3 To set up your data connection packages (BGAN
M2M)
Note
Note
4.3.1 To change the name of a connection package
To change the name of a connection package, go to the Dashboard and click
right side of the tile with the connection package.
Click Properties, type in the new name and click Save. The new name is shown on the
tile on the startup page.
4.3.2 To change the APN for a connection package
By default a connection package is set to use no IP Header compression and to use the
APN (Access Point Name) from the SIM card. This is suitable for most applications.
Note
If you want to use a different APN, do as follows:
1. Click
change.
2. Select Parameters.
3. Next to APN, select the source of the APN.
• SIM default (default and recommended setting): The APN is taken from the SIM
card.
• Network assigned: The APN is assigned from the network.
• User defined: APNs are provided from the Airtime Provider. Type in the APN next
to User defined name.
98-148232-K
This section only describes the Standard data connection available with M2M
subscriptions. For information on BGAN class 2 subscription, see To set up
data connections on page C-3.
You must be logged in as administrator to change the settings for a data
package.
It is recommended to leave IP Header compression disabled. This means
that the data packets are transmitted more reliably with less data loss.

in the right side of the tile with the connection package that you want to
Chapter 4: Configuration with web interface

To set up your data connection packages (BGAN M2M)


in the
4-6
