A.3 Built-in BGAN antenna
Item
Type
Polarization
Frequencies
Inmarsat I-4
Transmit
Receive
Inmarsat Alphasat (EMEA)
Transmit
Receive
GNSS
EIRP
Gain
1. Only available within Alphasat coverage (EMEA). See BGAN services on page 1-6.
98-148232-K
Specification
Directional patch array, manually adjustable
RHCP, Right-hand circular polarization for both Tx and
Rx
1626,5 MHz - 1660,5 MHz
1525 MHz - 1559 MHz
Extended L-band (XL)
1626,5 MHz - 1660,5 MHz and 1668 MHz - 1675 MHz
1518 MHz - 1559 MHz
GPS, GLONASS, BeiDou
Nominal: 15.1 dBW ±1dB, Class 2
11.25 dBi
