Specifications
Item
Number of connectors
Connector types
Standard
Max. data rate
Max. cable length
Typical power
consumption (when
running BGAN only)
(excluding PoE
injector)
1. The EXPLORER 540 is a Powered Device (PD), this means it may be powered by PoE from
external Power Sourcing Equipment (PSE), but it cannot supply PoE.
2. If you are using the optional EXPLORER 540 Cellular Modem, do not use PoE to power the
EXPLORER 540. Use the DC power input instead.
98-148232-K
Specification
2: X1 or X2 - only one at a time available!
The two connectors are on the same electrical interface.
RJ-45 female or spring loaded terminals
ISO/IEC 8877:1992 and PoE+ IEEE 802.3at type 2 class 4
1
(PD
10/100 Mbps
100 m / 328 ft with Cat5 UTP
Power save mode (wake on GPIO or timer): 2.4 W
Power save mode (wake on LAN): 2.3 W
Idle: 3.5 W
Transmitting: 21 W
2
Appendix A: Technical specifications
)
