Example: ADVWATCHDOG 2 1 1 24 100.100.100.130 100.100.100.110 200.247.237.254
In this example, the Terminal watchdog is set up as follows:
2: Set Terminal watchdog parameters.
1: Enable Terminal watchdog.
1: Wake up the terminal from power save.
24: Run the Terminal watchdog once a day (24 hours).
100.100.100.130: Primary IP address.
100.100.100.110: Secondary IP address.
200.247.237.254: Tertiary IP address.
0: Set the APN type to SIM default (0 = SIM default, 1 = Network assigned, 2 = User
defined).
NA: When the APN type is SIM default, the APN name is ignored.
CLR: The user name is cleared. When the default APN is used, any previous user
name and password should be cleared, unless a new manual user name is entered
(NA would maintain any previous setting).
CLR: The password is cleared. When the default APN is used, any previous user
name and password should be cleared, unless a new manual password is entered
(NA would maintain any previous setting).
NA: Position SMS response is not applicable (see note below).
NA: Number for position SMS response is not applicable (see note below).
Note
Response:
You do not get an OK response. You can use the ADVWATCHDOG 1 command to get
the settings of the ADVWATCHDOG feature.
See also Terminal watchdog on page 3-15 and SMS remote command summary on
page B-4.
ADPWRST: Reset the administrator password
To reset the administrator password you need the IMEI number of your terminal. If you
can access the web interface, you can find the IMEI number under Support > About,
see About on page 4-28.
The text in the ADPWRST SMS must have the following format:
ADPWRST 1 <imei> <rsms_pwd>
Example: To reset the administrator password of a terminal with the IMEI number
Response:
You receive a response with the result of the action.
Example: A response for a successful ADPWRST command, could be:
98-148232-K
0 NA CLR CLR NA NA remote
Position SMS response is for future use, and should be set to NA.
363833-09-012345, send an SMS with the text:
ADPWRST 1 36383309012345 remote
ADMIN RESET SUCCESS
SMS-Free: 88/100
WARNING: Ensure SMS-free > 5. Cleanup old msgs for
orderly Remote SMS Control
