Security Setup - COBHAM Satcom EXPLORER 540 User & Integrator's Manual

Example: If the IP address of the terminal is 161.30.180.12 and the incoming port
You should now be connected to the built-in web interface of the terminal.
Note

3.4 Security setup

Important
3.4.1 Overview of security measures
Since the EXPLORER 540 is most likely placed in remote areas without direct
supervision, it is important to protect it against unauthorized access.
The EXPLORER 540 has the following security measures:
• User and administrator passwords for the web interface.
• Deny access to AT commands on LAN.
• Admin password for AT shell and SMS control.
• White list for SMS control (list of trusted phone numbers).
• MAC filtering.
• SIM personalization.
Optional SIM lock (lock to provider) and optional PIN lock (lock to EXPLORER 540
terminal).
• Disable Reset button.
One of the functions of the Reset button is to reset to factory default, which also
resets the administrator password. This function can be disabled using the web
interface.
• Redirect to HTTPS.
• Enable/disable support for Thrane IP Handset.
You can set up these security measures in the web interface or with AT commands. see
the next sections for details.
98-148232-K
number defined in the Remote management page in the web interface is
80, enter
http://161.30.180.12:80.
Access to the EXPLORER 540 web interface is restricted with a password. See
Security setup on page 3-12 and Passwords on page 4-29.
By default any phone number can access the EXPLORER 540 with an SMS!
To protect against unauthorized access, change the remote SMS
password and make a list of trusted phone numbers. See To set up
remote access with SMS on page 4-40 and To set up the security with AT
commands below.
Chapter 3: Operation
Security setup
3-12
