WANMODE: Get or set the WAN connection mode
For information on the different WAN modes, see Select WAN network (Mode) on
page 4-15 and <wanmode> on page B-7.
Note
The text in the WANMODE SMS must have the following format:
WANMODE
Example: To set the connection mode to Cellular modem preferred, send an SMS
In this example, the WAN connection mode is set up as follows:
2: Set WANMODE parameters.
4: Select Cellular modem preferred.
Response:
You receive a response with the result of the action.
Example: The response to the command in the example above would be:
ATCO: Send AT commands to the EXPLORER 540
The text in the ATCO SMS must have the following format:
ATCO <resp_mode> <rsms_pwd> <at_cmd>
Example: To command the EXPLORER 540 to download new software from the
Response:
You receive a response with the result of the action. In this example we have chosen to
see only the final response (<resp_mode> = 2) and we have chosen immediate
upgrade (<mode> =1), so the final (and only) response will be related to the upgrade of
the EXPLORER 540.
Example: For a successful completion of the command in the above example, the
See also ATCO response codes on page B-12.
List of supported ATCO commands:
98-148232-K
If you are going to use one of the cellular modes (WANMODE 4, 6, 7 or 8), you
must first set up all dual mode parameters in the web interface or with AT
commands. See
• To set up the connection mode on page 4-15
• Optional: To set up cellular network for data (dual mode) on page 4-49
• PRISM/WAN switching on page 4-55
• AT commands for dual mode with cellular modem on page B-21
<cmd_op> {<wanmode>}
with the text:
WANMODE 2 4 remote
WANMODE=4
default FTP server via the default APN and upgrade to the new version
immediately, send an SMS with the text:
ATCO 2 remote _IGETFW=1
response would then be: _IUPDFW: 0, Complete
Chapter 3: Operation
To access the terminal from a remote location
<rsms_pwd>
