Parameter Values
<dns2> DNS 2 IP address.
To delete the entry, enter address
0.0.0.0
<ext> 0: Unknown / Down
1: Link up
<filename-url> <filename-url>
<intv> For BGAN (<mode> = 0):
4 to 2678400 seconds (31 days).
For LTE (<mode> = 1): 3 to 2678400
seconds (31 days).
<intv_fail> 3 to 255 seconds
<intvl> 2 to 255 seconds.
Default 120 seconds.
<ip> <IP address>.
<key> <shared authentication key>
<link_mode> 0: Always connected (default)
1: Connected when needed
<manual> 0 = Automatic operator
1 = Manual operator
<max_fail> 1 to 255
<mcc> 0-999 (if manual operator)
<mnc> 0-999 (if manual operator)
<mode> 0
1
<n> 1
2
<num_ok> 1 to 255
Default 10 ping replies
98-148232-K
Meaning
DNS address 2 (secondary server) of the
externally connected modem in dot-decimal
notation.
Link status of the External Modem connection.
Only applicable to QBG96 modem.
Type the URL from where the new firmware
can be downloaded.
Ping interval in seconds.
Ping interval after first failure.
Interval for pinging via primary connection to
determine if it is up.
IP address of the externally connected modem
in dot-decimal notation, or
IP address of the PRISM server.
To delete the entry, input 0.0.0.0.
Shared authentication key used for identifying
the terminal with the PRISM server.
Determines whether or not the BGAN backup
link is always up, or to be connected only when
the primary link is considered down.
Select 0 to use the operator from the SIM card
Select 1 to type in an operator manually (see
<mcc> and <mnc>).
Maximum number of failed ping attempts
before declaring the link down.
The Mobile Country Code
The Mobile Network Code
BGAN
LTE (Cellular)
Server number 1 (Primary)
Server number 2 (secondary)
Number of successful ping replies needed in
order to consider the primary link healthy.
