You install the EXPLORER 540 Cellular Modem as an integrated part of the
EXPLORER 540, but with the cellular antenna(s) installed externally, connected with
cable(s).
Note
For installation of the EXPLORER 540 Cellular Modem, see the installation guide that
comes with the modem.
For configuration, see Optional: To set up cellular network for data (dual mode) on
page 4-49.
1.5.2 External cellular modem via LAN
Instead of the EXPLORER 540 Cellular Modem you can purchase a stand-alone 3rd
party cellular modem/router with LAN interface and connect it to the EXPLORER 540
LAN interface.
For configuration, see To set up the EXPLORER 540 for cellular operation on page 4-49.
98-148232-K
Install the cellular antenna(s) min. 2 m. away from the EXPLORER 540, not in
front of the EXPLORER 540 BGAN antenna and not pointing through the
EXPLORER 540.
EXPLORER 540
Cellular Modem
(integrated)
Chapter 1: Introduction to EXPLORER 540
Optional: To use a cellular network (dual mode)
Cellular
antennas
