The following status is available:
Terminal status:
Note
• Network in use: The network currently used (BGAN or Cellular).
• (BGAN) status: The current status of the BGAN network. In the example in the
previous page, Data means a data connection is running. The status could also
be e.g. Registering or Ready.
• BGAN M2M SIM: Shows whether or not the BGAN SIM card is an M2M SIM (Yes or
No)
• (BGAN) current satellite: The satellite to which the EXPLORER 540 is currently
registered.
• (BGAN) spot beam: The type of spot beam currently used, e.g. Regional or
Narrow.
• (BGAN) signal strength: The signal strength of the BGAN connection.
• (BGAN) Airtime Provider: The provider of the BGAN services.
• Cellular status: The current status of the cellular network. In the example, a data
connection is running.
• Cellular network operator: The operator (or provider) of the Cellular network.
• Local IP address: The local IP address of the EXPLORER 540. E.g. used to connect
to the web interface.
• PRISM BGAN status: The status of the BGAN connection to the PRISM server
(Connecting or Connected)
• PRISM Cellular status: The status of the Cellular connection to the PRISM server
(Connecting or Connected)
• Logged in as: You can log in as User or Administrator. this field shows how you
are logged in.
Position information:
• Status: Shows the status of the GNSS connection, e.g. if there is 2D fix, 3D fix or
no fix.
• Position: The geographic position of the EXPLORER 540.
• GNSS: Shows which GNSS systems are currently used to obtain the position.
• Satellites used: Shows how many GNSS satellites are used to obtain the position.
Data information (only shown if a data connection is running):
• EXPLORER Cellular Modem: Shows which type of data is running on the cellular
connection.
• Standard data: Shows that a Standard data connection is running on the
Standard data connection package. This is the only option when the terminal is
running in one of the Cellular modem preferred modes.
• Data suspended: Data is temporarily suspended, e.g. due to a blockage.
Call information (only shown if a voice call is ongoing, not possible with M2M
subscription):
• Status: The status of the call, e.g. Connected or Ringing.
• Call type: Shows whether the call type is Standard voice or Premium voice (3.1
kHz Audio).
• Call duration: The duration of the call.
98-148232-K
If the terminal is running as BGAN only, the cellular status fields are not
shown. Likewise, the PRISM status fields are only shown if PRISM is used.
