AT_IMACLOCAD=1,0,<MAC address>[,<MAC address> (etc.)]
Example: AT_IMACLOCAD=1,0,00:B5:E0:76:FD:C2,00:B5:A0:84:F9:E2
When you get an OK reply, the specified MAC addresses are added to the white list.
Important
6. Turn on MAC address filtering:
AT_IMACLOC=1,0
When you get an OK reply, MAC address filtering is enabled for Ethernet, and only
the MAC addresses specified in the white list can get access (previous step).
7. Enable administration lock:
AT_ICLCK=AD,1,<password>
Example: AT_ICLCK=AD,1,myadmpwd
When you get an OK reply, the system is protected with the administrator
password.
3.4.3 To set up the security with the web interface
If you want to set up the security with the web interface, see the following sections:
• User and administrator passwords for web interface: Passwords on page 4-29.
• Admin password for AT shell (same as for web interface): Passwords on page 4-29.
• Password for remote SMS access: To set up remote access with SMS on page 4-40.
• Trusted phone numbers for SMS control: To set up remote access with SMS on
page 4-40.
• MAC filtering: To manage connected devices (Traffic control) on page 4-21.
• SIM personalization: Auto SIM PIN validation on page 4-32 and SIM lock on page 4-
32.
• Disable Reset button: Reset button on page 4-46.
• Access to AT commands on LAN: Security on page 4-46.
• Redirect to HTTPS: Security on page 4-46.
• Support for Thrane IP Handset: To enable the use of Thrane IP Handset on page C-9.
98-148232-K
Remember to add the MAC address of your own device. Enabling the
MAC address locking without adding your own device MAC address
will block for any local access to the Terminal!
