Important
2. Select how many minutes with no activity before the terminal should enter power
save state (Idle time before power save).
3. Select Prevent power save if satellite connection is active if you do not want the
terminal to enter power save state while a data connection (PDP context) is opened
on the satellite connection.
Note
4. Under Daily wake up, select Enable and enter the Wake up time of day if you want
the terminal to "wake up" from power save state at a specific time every day.
Note
5. Under Wake-on-LAN, select Enable if you want the terminal to wake up from
power save when the LAN port receives a magic packet from locally connected
equipment.
6. Under Power control pin, select Enable wake up when activated if you want to
use the power control signal (e.g. connected to the ignition of your vehicle) to wake
up the terminal from power save state.
Note
Set the polarity (Active high/Active low) for the power control pin.
7. Click Save.
98-148232-K
When you select Idle power save mode you must enable minimum
one wake-up method (Daily wake up, Wake-on-LAN and/or Power
control pin).
With this option selected, the terminal will not enter power save state if
there is a PDP context open, even if it is not currently used to send or
receive data.
Local time must be converted to UTC time!
With this option selected the terminal will be active when the Power
control pin is active.
