4.2 To control data connections from web interface

The startup page of the web interface is used to start and stop data connections and to
set up the data connections.
Note
4.2.1 To start and stop data connections
By default, you must activate your data connection before you can access the Internet.
However, you can enable Automatic Context Activation, see Automatic Context
Activation (ACA) on page 4-7.
Note
To start and stop data connections on your EXPLORER 540, do as follows:
1. In the opening page, locate the connection package you want to start.
2. Click
shows
3. Click
If data is temporarily suspended, e.g. due to a blockage, the icon on the active
connection turns yellow in stead of green, and the Status field shows Data
suspended.
If the connection fails, the connection tile shows an exclamation mark
message. The error message is also shown in the data log, see Data log on page 4-14.
When a connection is active, the icon changes to
connection shows:
98-148232-K
With a non-M2M subscription you have more options for the data connection.
See Appendix C, BGAN non-M2M functions.
The icons for starting
terminal is ready and registered on the BGAN network. Otherwise the text is
grayed out and you cannot start data connections.
If a connection is automatically activated (has ACA enabled), the icons for
starting
and stopping are replaced by a lock symbol
If you have a cellular modem installed and the EXPLORER 540 is in one of the
Cellular modem preferred modes, you cannot start and stop data
connections. For details, see Limitations in Cellular modem preferred mode
and External modem preferred mode on page 4-60 and To set up the
connection mode on page 4-15.

to start the connection. The connections icon at the bottom of the page
when a BGAN data connection package is running.

to stop the connection.
Chapter 4: Configuration with web interface
To control data connections from web interface
 
and stopping connections are only active if the


.

and an error
and the tile for the active
4-5
