3.6 Power control

You can configure the Power mode options with the web interface and with AT
commands.
With the web interface you can set up what should make the EXPLORER 540 enter
power save state as well as how and when to wake up the terminal. For details, see
Power control on page 4-42.
With AT commands you can set up: Idle power save and Remote on/off. See To set up
power save functions with AT commands on page 3-22.
You can choose between three modes:
• Always on. This is the default setting. The terminal will never go into power save
state but will always be on when connected to power.
• Remote on/off. The terminal will go into power save state when the Power
control pin (Remote on/off signal) is inactive. For details, see the following
section Remote on/off.
• Idle power save. The terminal will go into power save state after a (configured)
period with no activity. For details, see Idle power save on page 3-21.
3.6.1 Always on
Always on is the default mode where the terminal stays on as long as power is
connected.
3.6.2 Remote on/off
When Remote on/off is selected in the web interface or with AT commands, you can
control the power save function using the Power control pin (Remote on/off signal).
Wake-up methods in Remote on/off mode:
• Power control pin (Remote on/off signal) is active. See the next section for details.
• Daily awake period
You can configure the function in the web interface (see Power control on page 4-42) or
with AT commands (see Remote on/off on page 3-22).
Note
Power control pin function when Remote on/off is selected
You can set the polarity of the Power control pin, that is whether the pin should be
active high or low. Default is active low.
The function of the Power control pin in Remote on/off mode is:
Power control pin is active: The terminal is on and will stay on as long as the pin is
active.
Power control pin is inactive: The terminal will attempt to go into power save state.
However, a number of conditions may keep the terminal awake even if the Power
control pin is inactive:
98-148232-K
To use the Remote on/off function you must first connect the Power control
pin to a remote on/off switch as described in Connection example for the
Power control pin on page 3-20.
