COBHAM Satcom EXPLORER 540 User & Integrator's Manual page 87

To change the default settings for all devices
Important
1. Click the button Default settings.
2. Select Block BGAN traffic or Block Cellular modem traffic (if available) if you
want to deny access to BGAN or cellular network for all devices. With this option
selected, only the administrator will be able to allow access for selected or all
devices.
3. Click Save.
All devices in the list will now have the new default settings.
To block or allow BGAN or cellular traffic or edit the name for a device
1. In the Traffic control page, click the device you want to set up.
The page shows the name, MAC address, IP address and traffic rule for the device.
2. Select Block BGAN traffic or Block Cellular traffic, if you want to deny access to
the BGAN or cellular network for the selected device.
If you want to allow access, clear the box. The selected device will then be able to
access the network, even if it is blocked in the default settings (see previous
section).
3. At Name, type in the name you want for your device.
4. Click Save.
Reset to default: You can reset the settings for the device to the default settings.
• If the device is connected and you click the button Reset to default, the traffic rules
will be reset to the default values set in the previous section, but the name remains
the same.
• If the device is not connected and you click the button Reset to default, the device
is removed from the list.
To Add a device
When you connect a device, it is automatically added to the list using the default
settings. If you want to add a device for later use, do as follows:
1. In the Devices page, click the Add device button.
2. Type in the Name and the MAC address for the device.
3. Select Block BGAN traffic or Block Cellular modem traffic, if you want to deny
access to BGAN or cellular network for the selected device.
If you want to allow access, clear the box. The device will then be able to access the
network, even if it is blocked in the default settings (see previous section).
4. Click Save.
When the device with this MAC address is connected, it will appear with the entered
name in the list, and access will be allowed or denied depending on the setting in this
page.
98-148232-K
All devices in the list are updated with the default settings when you click
Save.
Chapter 4: Configuration with web interface
To manage connected devices (Traffic control)
4-23
