COBHAM Satcom EXPLORER 540 User & Integrator's Manual page 115

Note
5. If required, select
cellular connection. For details, see the next section.
When the connection is established, an "M" on the signal bar in the top right corner
indicates that it is a cellular (Modem) connection, and the tile shows details about the
connection.
The data connection is automatically established when set up correctly, so you cannot
start and stop connections from the tiles as you can when the terminal is in BGAN
mode.
Note
You can now access the Internet through the cellular network from a device connected
to the EXPLORER 540.
Note
4.15.2 To set up the EXPLORER 540 Cellular Modem
Note
Note
To set or change the APN for your cellular connection
If the APN for your cellular connection is not set up automatically, you must set it up
before you can connect to the cellular network. Do as follows:
1. Select
2. Type in the new name for your connection.
3. Type in the name of the APN you are going to use for your cellular connection.
4. If required, type in user name and password for your APN.
5. Click Save.
98-148232-K
If the BGAN link mode in the PRISM/WAN switching page is set to Always
connected, the Standard data connection on the BGAN network will still
be running in the background and cannot be stopped. See PRISM/WAN
switching on page 4-55.

on the tile to set or change the name or the APN of your
You may have to enter a PIN before you can use the cellular network, see To
enter the SIM PIN in the web interface on page 4-48.
You cannot make calls on the cellular network through the EXPLORER 540.
Only data connection is possible.
This section is only for the EXPLORER 540 Cellular Modem. If you have an
external modem connected to LAN, you must set up the APN, SIM PIN and
other settings in the modem. See To set up an external cellular modem on
page 4-54.
You may not have to change any of the EXPLORER 540 Cellular Modem
settings below. The default settings will apply to most setups.

on the tile with the cellular connection.
Chapter 4: Configuration with web interface
Optional: To set up cellular network for data (dual mode)
4-51
