COBHAM Satcom EXPLORER 540 User & Integrator's Manual page 177

Parameters for context management AT commands
The table below summarizes the main parameters for the AT commands for context
management. For details, refer to the 3GPP standard TS 27.007.
Parameter Values
<apn passwd> <apn passwd>
<apn uname> <apn uname>
<apn> <apn>
<cid> <cid>
<d_comp> 0
<destination <destination
port range> port range>
<evaluation <evaluation
precedence precedence
index> index>
<Guaranteed <Guaranteed
bitrate DL> bitrate DL>
0
<Guaranteed <Guaranteed
bitrate UL> bitrate UL>
0
<h_comp> 0
1
<Max bitrate <Max bitrate
DL> DL>
0
<Max bitrate <Max bitrate
UL> UL>
0
<p_cid> <p_cid>
<packet filter <packet filter
identifier> identifier>
<PDP_addr> <PDP_addr>
98-148232-K
Meaning
Password for the APN.
User name for the APN.
APN name.
The Context Identifier (1 – 11) for the PDP context.
If no cid is entered, the command applies to all defined PDP contexts.
Data compression off (default if value is omitted)
Destination port range in the form From.To
To indicate only one port number, type in the same port number under
From and To.
Example: 65333.65338 indicates port numbers from 65333 to
65338, both included.
The evaluation precedence index defines the order in which the traffic
flow filters are applied to packets. 0 is first, then 1, 2 etc.
The guaranteed bit rate down link (32, 64, 128).
If the parameter is set to '0' the subscribed value will be requested.
The guaranteed bit rate up link (32, 64, 128).
If the parameter is set to '0' the subscribed value will be requested.
Header compression off (default if value is omitted)
Header compression on (manufacturer preferred compression)
The maximum bit rate down link (32, 64, 128).
If the parameter is set to '0' the subscribed value will be requested.
The maximum bit rate up link (32, 64, 128).
If the parameter is set to '0' the subscribed value will be requested.
The primary context to which the secondary context is related.
The packet filter identifier (1 – 8).
Omit this parameter - note that the comma must still be there if other
parameters come after this one.
Appendix B: Command reference
AT commands
B-19
