COBHAM Satcom EXPLORER 540 User & Integrator's Manual page 184

2. Click
package, this will start all included connections. The connections icon at the
bottom of the page shows
Note
3. Click
If data is temporarily suspended, e.g. due to a blockage, the icon on the active
connection turns yellow in stead of green, and the Status field shows Data
suspended.
If the connection fails, the connection tile shows an exclamation mark
message. The error message is also shown in the data log, see Data log on page 4-14.
When a connection is active, the icon changes to
connection shows:
• IP address: The IP address that has been assigned by the service provider to this
session.
• Transferred data: For Standard data, the tile shows the total amount of transmitted
and received data since the connection was established.
• Connection duration: For Streaming data, the tile shows the total time the
connection has been active.
• Bit rate: For Streaming connections, the tile shows the fixed bit rate.
C.1.2 Default data connection types
By default, the following connections are available:
Name
Standard data
Streaming data
The following Streaming classes
are available:
32, 64, or 128 Streaming
You can use these connections as they are or build your own connection packages. For
set up of the connection packages, see the next section.
98-148232-K

to start the connection. If more connections are included in the connection
Once a Streaming connection is started, the connection will run until you
stop it. You will be charged for the time you are connected.

to stop the connection.
Appendix C: BGAN non-M2M functions
To control data connections from web interface (BGAN)
when a BGAN data connection package is running.

and the tile for the active
Type of connection
Several users can share the data connection. This
type of connection is ideal for TCP/IP traffic such as
e-mail, file transfer, and Internet/intranet access.
The user pays for the amount of data sent and
received.
An exclusive, high-priority connection, ensuring
seamless transfer of data. This type of connection
is ideal for time critical applications like live video
over IP.
The user pays for the duration of the connection.
Note that Streaming is not available in M2M
subscriptions.

and an error
C-2
