Overview of the web interface
When the web interface opens, the title bar shows the name of the product. The
example below shows the Support page.
Name and icon of current page (on opening page: the name of the product)
Breadcrumbs
Contents
section
The web interface consists of the following sections.
• Name of current page. Tap or click to refresh the page.
• Icon bars at the top and bottom are present on all pages and hold icons that give
access to status such as signal level as well as active alerts, when relevant. It also
holds the icon for the Control panel. For explanations of the icons, see the next
section, Icons in the icon bars.
• Breadcrumbs right below the icon bar show the current location in the menu
system and gives access to the higher levels in the menu.
• Contents section shows the contents of the selected page. This section is used for
viewing or changing settings, or for performing actions. On the opening page, this
section is used to start and stop data connections.
• Status section shows the status of the terminal and the network connection (BGAN
and Cellular if used), position information, ongoing calls and data sessions etc. The
Status section is not shown on small screens. If the screen is small (e.g. on a
smartphone), you can show/hide the status by clicking
page.
98-148232-K Chapter 4: Configuration with web interface
The web interface

at the bottom of the
Icon bar
Status
section
Icon bar
