See ATCO commands on page B-10 for syntax and parameters.
1. To use an SMS to allow access to the web interface for specific IP addresses, send
the following command:
ATCO <resp_mode> <rsms_pwd> _IREMWEB=1,<ip address>[,<ip address>]
Example: ATCO 2 remote _IREMWEB=1,214.123.189.119
In this example the command specifies no immediate response, only when the
global IP address is sent along (2). The remote SMS password is remote and the IP
address 214.123.189.119 can get remote access to the web interface (if two IP
addresses are listed, it is interpreted as a range of IP addresses).
2. The EXPLORER 540 should now return an SMS response with the external IP
address of the terminal.
Example: _IREMWEB:81, GlobalIP:161.30.181.31
81 is the response code for a remote web connection that was set up successfully.
It is followed by the global IP address, which is the IP address to enter in your
browser to access the web interface from the remote device with the IP address
you specified in the command.
3. On the remote computer, open your web browser.
4. In the address bar of your browser, enter the global IP address of the EXPLORER 540
(received in the response above).
You should now be connected to the built-in web interface of the terminal.
Note
To get remote access to the web interface from a trusted IP address
(preconfigured)
Note
1. Connect a computer to the EXPLORER 540 and access the web interface locally.
2. Prepare the terminal as described in Remote management on page 4-39.
3. Make sure your remote computer has access to the Internet.
4. On the remote computer, open your web browser.
5. In the address bar of your browser, enter the IP address of the terminal followed by
a colon and the port number
http://<ip address>:<incoming port>.
• <ip address> is the external IP address of the EXPLORER 540. The external IP
address can only be obtained when a data connection (PDP context) is
established. If a data connection is started. you can get the external IP address
with the GETINFO SMS command, see GETINFO: Get information from the
EXPLORER 540 on page 3-6.
• <incoming port> is the port you defined in Remote management on page 4-39
(Incoming port for web application, default port 80).
98-148232-K
Access to the EXPLORER 540 web interface is restricted with a password. See
Security setup on page 3-12 and Passwords on page 4-29.
This method requires that you initially have local access to the
EXPLORER 540. If not, use the _IREMWEB command described in the previous
section.
