CPM2A/CPM2C High-speed Counters
ON for 1 cycle at beginning
of operation
Always ON
Always ON
Always ON
Always ON
Always ON
Programming
(71)
Register range comparison table and begin comparison
(63)
High-speed counter
Register range comparison table and begin comparison
Beginning word of comparison table
(92)
Comparison 1
(38)
(93)
(92)
(38)
Comparison 2
(93)
(92)
(38)
Comparison 3
(93)
(92)
(38)
Comparison 4
(93)
(92)
(38)
Comparison 5
(93)
(01)
Section
Lower limit:
9,000
Comparison 1
Upper limit:
10,000
Subroutine 040
Lower limit:
7,000
Comparison 2
Upper limit:
8,000
Subroutine 041
Lower limit:
3,000
Comparison 3
Upper limit:
–3,000
Subroutine 010
Lower limit:
–8,000
Comparison 4
Upper limit:
7,000
Subroutine 042
Lower limit:
–10,000
Comparison 5
Upper limit:
9,000
Subroutine 043
Comparison 6 Not used.
Comparison 7 Not used.
Comparison 8 Not used.
