CPM2A/CPM2C Pulse Output Functions

Combination
Single-phase Fixed duty
pulse output ratio
Variable
duty ratio
Pulse + direction output
Up/down pulse output
Types of Pulse Outputs
98
Note 1. With single-phase pulse outputs, pulse outputs 0 and 1 can each be output
independently.
2. Pulse outputs can be accelerated or decelerated in units of 10 Hz every
10 ms.
3. Actual pulses are affected by the transistor output's ON response time
(20 s max.) and OFF response time (40 s max.).
The following table shows the relationships between the high-speed counter
and the CPM2A/CPM2C's other functions.
Synchronized pulse control
Interrupt inputs

Interval timer interrupts

High-speed counters
Interrupt inputs (counter mode)
Pulse outputs
Quick-response inputs
Input time constant
Clock
Note The number of simultaneous outputs varies according to the type of pulse out-
put, as shown in the following table.
Single-phase pulse output
Fixed duty ratio
Can use two points Can use one point at a
simultaneously time (independently).
(independently).
Can use one point at a Can use two points
time (independently). simultaneously
(independently).
Cannot be used. Cannot be used.
Cannot be used. Cannot be used.
Up to two points can be output simultaneously with only single-phase pulse out-
puts, so two-point output is possible when fixed duty ratio and variable duty ratio
are used in combination.
Outputs are possible for only one point at a time with pulse + direction outputs
and up/down pulse outputs, so no other pulses can be output.
There are three types of pulse outputs: Single-phase pulse outputs without ac-
celeration and deceleration, variable duty ratio pulse outputs, and single-phase
pulse outputs with trapezoidal acceleration and deceleration.
Single-phase Pulse Outputs Without Acceleration and Deceleration
Frequency:
Output destination:
Output mode:
Number of pulses:
Cannot be used simultaneously.
Can be used simultaneously.
Can be used simultaneously.
Can be used simultaneously.
Can be used simultaneously.
See note.
Can be used simultaneously.
Can be used simultaneously.
Can be used simultaneously.
Pulse + direction
Variable duty ratio
Cannot be used.
Cannot be used.
Cannot be used.
Cannot be used.
10 Hz to 10 kHz (Set in units of 10 Hz.)
Output number 01000 (Word 010, bit 00)
Output number 01001 (Word 010, bit 01)
(Pulses can be output simultaneously and indepen-
dently from two points.
Continuous or Independent
1 to 16,777,215
Section
Interval timer interrupts
Up/down pulse p
output output
Cannot be used.
Cannot be used.
Cannot be used.
Cannot be used.
