Expansion Instructions (CPM2A/CPM2C/SRM1(-V2) Only)

2-18-2 SRM1(-V2) Expansion Instructions

162
The following 18 function codes can be used for expansion instructions: 17, 18,
19, 47, 48, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 87, 88, and 89. The function
code assignments can be changed with a Programming Console or the Support
Software.
Refer to 4-2-6 Setting Expansion Instructions in the SRM1 Master Control Unit
Operation Manual for the Programming Console procedure. Refer to the SSS
Operation Manual: C-series PCs for the SSS procedure. Refer to the SYSMAC-
CPT Support Software Quick Start Guide (W332) and User Manual (W333) for
the SYSMAC-CPT Support Software procedure.
The expansion instructions that can be used are listed below, along with the de-
fault function codes that are assigned when the SRM1(-V2) is shipped.
Mnemonic
ASFT 17
--- 18
--- 19
RXD 47
TXD 48
CMPL 60
--- 61
--- 62
--- 63
--- 64
--- 65
SCL* 66
BCNT 67
BCMP 68
STIM 69
--- 87
--- 88
--- 89
FCS ---
HEX ---
NEG* ---
PID* ---
STUP ---
ZCP* ---
Note *SCL(66), NEG(––), PID(––), and ZCP (––) are supported by the
SRM1-C0j-V2 CPUs only.
Function code
Section 2-18
