Omron CPM1 - PROGRAMING MANUAL 02-2001 Programming Manual page 84

CPM2A/CPM2C High-speed Counters
Wiring (CPM2C)
Note The following examples are for Fujitsu-compatible connectors. Input bit ad-
dresses and connector pin numbers depend on the models. Refer to the CPM2C
Operation Manual (W356) or the CPM2C-S Operation Manual (W377) for de-
tails.
Input terminals
Input connector
(See above note.)
PC Setup
15
DM 6642
Brown
Orange
White
Black
Brown
Orange
White
Black
0
0 1 0 0
0: Differential phase input
0: Reset by phase-Z signal + software reset
01: Use as high-speed counter
Section
Blue
Rotary encoder
Blue
Rotary encoder
2-2
63
