Coding Right-hand Instructions
00000 00001
00002
00100 00200
01001 01002 LR 0000
00005
TIM 000
HR 0015
368
The following diagram and corresponding mnemonic code illustrates the points
described previously.
21600
Address Instruction
DIFU(13) 21600 00000
00001
00002
00003
BCNT(67)
00004
#0001
00005
004
00006
HR 00
00007
00008
00009
TIM 000
00010
#0150
00011
MOV(21)
HR 00
LR 00
00012
00013
01000
00014
00015
00016
00017
Section 7-5
Data
LD 00000
AND 00001
OR 00002
DIFU(13) 21600
LD 00100
AND NOT 00200
LD 01001
AND NOT 01002
AND NOT LR 0000
OR LD ––
AND 21600
BCNT(67) ––
# 0001
004
HR 00
LD 00005
TIM 000
# 0150
LD TIM 000
MOV(21) ––
HR 00
LR 00
LD HR 0015
OUT NOT 01000
