CPM2A/CPM2C Cycle Time and I/O Response Time
Code Mnemonic ON execution
time ( s)
63 CTBL 186.0
807.5
185.8
781.9
410.0
418.9
380.6
399.7
183.4
810.3
182.4
776.3
351.0
359.1
331.2
335.9
64 SPED
44.6
53.8
42.9
52.0
34.1
39.8
532
Conditions (Top: min.; bottom: max.)
Registering a target value comparison table and
starting comparison in incrementing/decrement-
ing pulse input mode via word
Registering a target value comparison table and
starting comparison in incrementing/decrement-
ing pulse input mode via :DM
Registering a target value comparison table and
starting comparison in incrementing mode via
word
Registering a target value comparison table and
starting comparison in incrementing mode via
:DM
Registering a range comparison table and start-
ing comparison in incrementing/decrementing
pule input mode via word
Registering a range comparison table and start-
ing comparison in incrementing/decrementing
pule input mode via :DM
Registering a range comparison table and start-
ing comparison in incrementing mode via word
Registering a range comparison table and start-
ing comparison in incrementing mode via :DM
Only registering a target value comparison table
in incrementing/decrementing pulse input mode
via word
Only registering a target value comparison table
in incrementing/decrementing pulse input mode
via :DM
Only registering a target value comparison table
in incrementing mode via word
Only registering a target value comparison table
in incrementing mode via :DM
Only registering a range comparison table in
incrementing/decrementing pule input mode via
word
Only registering a range comparison table in
incrementing/decrementing pule input mode via
:DM
Only registering a range comparison table in
incrementing mode via word
Only registering a range comparison table in
incrementing mode via :DM
Specifying a constant in independent mode
Specifying :DM in independent mode
Specifying a constant in continuous pulse out-
put mode
Specifying :DM in continuous pulse output
mode
Specifying a word when changing output fre-
quency
Specifying :DM when changing output fre-
quency
Section
OFF execution time ( s)
2.6
2.6
8-2
