CompoBus/S I/O Master Functions (SRM1(-V2) and CPM2C-S Only)

2-12 CompoBus/S I/O Master Functions (SRM1(-V2) and
CPM2C-S Only)
Maximum Number of Nodes
Slave Interrupts
148
A maximum of either 16 or 32 CompoBus/S nodes may be connected.
Communications mode
High-speed mode g p
Long-distance mode g
The communications mode and maximum number of nodes are set in the PC
Setup, as shown in the following table.
Word Bit(s)
DM 6603 00 to 03
04 to 07
08 to 15
Note When changes are made to these settings, always turn the power off and on
again to make the new setting effective.
Input bits in IR 000 to IR 007 and output bits in IR 010 to IR 017 are used as inter-
rupts for CompoBus/S I/O Terminals. The CompoBus/S I/O Terminal interrupts
(IN 0 to 15 and OUT 0 to 15) are allocated as indicated in the following table.
IN0 to IN15 are the node addresses for the Input Terminals and OUT0 to OUT15
are the node addresses for the Output Terminals.
Word
15 14 13 12 11 10 9
Input p
IR 000
IR 001
IR 002
IR 003
IR 004
IR 005
IR 006
IR 007
Output IR 010 p
IR 011
IR 012
IR 013
IR 014
IR 015
IR 016
IR 017
Note 1. When the maximum number of CompoBus/S nodes is set to 16, IN8 to IN15
can be used as work bits.
2. CompoBus/S Terminals with less than 8 points are allocated bit addresses
from either 0 or 8.
No. of nodes set
16 0.5 ms
32 0.8 ms
16 4.0 ms
32 6.0 ms
Function
Maximum number of CompoBus/S nodes
0: 32 nodes
1: 16 nodes
CompoBus/S communications mode
0: High-speed communications
1: Long-distance communications
Not used.
8 7
IN1
IN3
IN5
IN7
IN9
IN11
IN13
IN15
OUT1
OUT3
OUT5
OUT7
OUT9
OUT11
OUT13
OUT15
Section
Communications response time
Setting
0 or 1
0 or 1
00
Bit
6 5 4 3 2
IN0
IN2
IN4
IN6
IN8
IN10
IN12
IN14
OUT0
OUT2
OUT4
OUT6
OUT8
OUT10
OUT12
OUT14
2-12
1 0
