Omron CPM1 - PROGRAMING MANUAL 02-2001 Programming Manual page 537

CPM1/CPM1A Cycle Time and I/O Response Time
Code Mnemonic ON execution
time ( s)
15 TIMH
19.0
20.2
19.0
20.2
16 WSFT
29.2
40.7
1.42 ms
17 ASFT 29.6
50.2
1.76 ms
20 CMP
15.8
17.2
46.3
21 MOV 16.3
17.7
45.5
22 MVN 16.4
17.5
45.7
23 BIN
31.6
45.7
24 BCD
29.5
57.3
25 ASL 17.3
31.3
26 ASR 16.9
31.1
27 ROL 14.5
28.5
28 ROR 14.5
28.5
29 COM
18.1
32.1
30 ADD
29.5
30.9
72.7
31 SUB 29.3
30.5
72.5
32 MUL 49.1
50.5
95.1
33 DIV
47.7
50.9
94.3
34 ANDW 27.1
28.7
70.7
Conditions (Top: min.; bottom: max.)
Regular execution, constant for SV
Interrupt execution, constant for SV
Regular execution, :DM for SV
Interrupt execution, :DM for SV
With 1-word shift register
With 10-word shift register
With 1,024-word shift register using :DM
Shifting a word
Shifting 10 words
Shifting 1,023 words via :DM
When comparing a constant to a word
When comparing two words
When comparing two :DM
When transferring a constant to a word
When transferring from one word to another
When transferring :DM to :DM
When transferring a constant to a word
When transferring from one word to another
When transferring :DM to :DM
When converting a word to a word
When converting :DM to :DM
When converting a word to a word
When converting :DM to :DM
When shifting a word
When shifting :DM
When shifting a word
When shifting :DM
When rotating a word
When rotating :DM
When rotating a word
When rotating :DM
When inverting a word
When inverting :DM
Constant + word word
Word + word word
:DM + :DM :DM
Constant – word word
Word – word word
:DM – :DM :DM
Constant  word
word
Word  word
word
:DM  :DM :DM
Word constant word
word word word
:DM :DM :DM
Constant word word
Word word word
:DM :DM :DM
Section
OFF execution time ( s)
Reset IL JMP
25.7 28.4 15.8
41.2 43.6 15.8
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.5
5.5
5.5
5.5
5.5
5.6
5.6
5.6
5.6
5.6
8-1
519
