CPM2A/CPM2C Cycle Time and I/O Response Time
Code Mnemonic ON execution
time ( s)
35 ORW 12.3
13.8
35.4
36 XORW
12.3
13.8
35.4
37 XNRW
12.3
13.8
35.5
38 INC 8.8
15.9
39 DEC 8.9
16.1
40 STC 3.0
41 CLC 3.0
46 MSG
9.9
17.8
47 RXD 71.9
314.5
48 TXD 32.4
264.5
27.7
42.2
50 ADB
14.1
15.6
37.4
51 SBB 14.4
15.9
37.7
52 MLB
16.8
18.5
41.2
53 DVB
16.9
18.6
41.3
54 ADDL 25.3
48.6
55 SUBL 25.3
48.6
56 MULL
79.1
102.1
57 DIVL
73.9
98.6
58 BINL 23.9
38.5
59 BCDL 19.1
33.7
60 CMPL 14.8
30.6
530
Conditions (Top: min.; bottom: max.)
Constant V constant word
Word V word word
:DM V :DM :DM
Constant V constant word
Word V word word
:DM V :DM :DM
Constant V constant word
Word V word word
:DM V :DM :DM
When incrementing a word
When incrementing :DM
When decrementing a word
When decrementing :DM
Any y
With message in words
With message in :DM
Word specification, 1 byte input
:DM specification, 256 bytes input
Word specification, 1 byte input, RS-232C
:DM specification, 256 bytes input, RS-232C
Word specification, 1 byte input, Host Link
:DM specification, 256 bytes input, Host Link
Constant + constant word
Word + word word
:DM + :DM :DM
Constant – constant word
Word – word word
:DM – :DM :DM
Constant  constant
word
Word  word
word
:DM  :DM :DM
Constant constant word
Word word word
:DM :DM :DM
Word + word word
:DM + :DM :DM
Word – word word
:DM – :DM :DM
Word  word
word
:DM  :DM :DM
Word word word
:DM :DM :DM
When converting word data to a word
When converting :DM to :DM
When converting word data to a word
When converting :DM to :DM
Comparing words
Comparing :DM
Section
OFF execution time ( s)
2.6
2.6
2.6
2.5
2.5
2.5
2.5
2.5
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
