Omron CPM1 - PROGRAMING MANUAL 02-2001 Programming Manual page 539

CPM1/CPM1A Cycle Time and I/O Response Time
Code Mnemonic ON execution
time ( s)
63 CTBL 106.3
120.3
775.5
799.5
711.5
722.5
91.9
106.3
693.5
709.5
607.5
621.5
64 SPED 73.6
75.0
88.8
65 PULS 62.0
78.0
67 BCNT
52.6
4.08 ms
68 BCMP
79.6
80.8
123.2
69 STIM
47.5
58.7
47.9
59.1
33.5
63.5
25.7
54.1
70 XFER
45.5
47.1
1.78 ms
71 BSET
28.1
38.3
1.12 ms
73 XCHG
30.5
59.1
74 SLD
25.9
51.7
3.02 ms
75 SRD 25.9
51.7
3.02 ms
76 MLPX
47.7
92.7
77 DMPX 59.5
95.5
Conditions (Top: min.; bottom: max.)
Target table with 1 target in words and start
Target table with 1 target in :DM and start
Target table with 16 targets in words and start
Target table with 16 targets in :DM and start
Range table in words and start
Range table in :DM and start
Target table with 1 target in words
Target table with 1 target in :DM
Target table with 16 targets in words
Target table with 16 targets in :DM
Range table in words
Range table in :DM
Specifying a constant
Specifying a word
Specifying :DM
Specifying a word
Specifying :DM
Counting a word
Counting 6,656 words via :DM
Comparing constant, results to word
Comparing word, results to word
Comparing :DM, results to :DM
Word-set one-shot interrupt start
:DM-set one-shot interrupt start
Word-set scheduled interrupt start
:DM-set scheduled interrupt start
Word-set timer read
:DM-set timer read
Word-set timer stop
:DM-set timer stop
When transferring a constant to a word
When transferring a word to a word
When transferring 1,024 words using :DM
When setting a constant to 1 word
When setting word constant to 10 words
When setting :DM to 1,024 words
Word word
:DM :DM
Shifting 1 word
Shifting 10 word
Shifting 1024 words using :DM
Shifting 1 word
Shifting 10 word
Shifting 1,024 words using :DM
When decoding word to word
When decoding :DM to :DM
When encoding word to word
When encoding :DM to :DM
Section
OFF execution time ( s)
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
5.6
8-1
521
