Omron CPM1 - PROGRAMING MANUAL 02-2001 Programming Manual page 615

Revision Date
code
03 February 2001
04 July 2003
05 February 2004
06 February 2008
604
Revision History
Revisions and additions were made accompanying specifications changes and new products.
The CPM1A-MAD11 Analog I/O Unit was added as section 3-1-2 and the CPM1A-DRT21 DeviceNet I/O Link Unit was
added as section 3-4.
Interrupt programming precautions were added to sections 2-1 and 2-3.
Specific changes are as follows:
Pages xi, 1, 23, 148, 163, 177, 197, 203, 331, 341, 383, 495, 500, and 546: CPM2C-S added.
Pages 7 and 21: Information added on DIP switch changes.
Page 138: Note added.
Page 161: Information added on startup operation.
Page 162: Programming example modified.
Pages 295 to 298 and 300: Models added.
Page 545: Description of AR 1314 altered.
Page 550: Description of AR 0712 added.
The following revisions and changes were made.
Page xi: Support Software information updated.
Page xv: Caution added.
Page 27: Section added.
Page 164: Bottom illustration changed.
Pages 170, 411, and 413: Notes added.
Page 183: Range for range code 011 corrected, note following table changed, and top illustration corrected.
Page 202: DM area address corrected for SBB and BCD instructions at bottom of ladder program code.
Page 216: Communications current consumption added to top table.
Page 219: Callouts in top illustration corrected.
Pages 229, 231, 257, and 261: "-V1" version added to illustration.
Pages 240 and 248: "-V1" added to version in note.
Page 251: Recommended cables added.
Page 313: Model number added at top of page.
Pages 385 to 388, 390, and 391: Timer/counter notation changed in introductions.
Pages 387 and 389: "TML(––)" corrected to "the Programming Console."
Page 388: Programming example corrected.
Page 549: Information added to description of F7 in table.
The following revisions and changes were made.
Page xi: CX-Programmer information updated in table.
Page 131: Catalog number of manual added.
Pages 214 and 219: "CS1" changed to "CS."
Page 233: Note changed.
Page 397: Note added.
Page xii: Added information on warranty and liability.
Page 7: Changed description of a setting of 00 for bits 08 to 15 of CM 6600.
Page 71: Replaced top two graphics.
Page 186: Changed number of Analog I/O Units to 3 and added note.
Page 187: Changed analog input numbers in table column headings.
Page 214: Changed bottom callout in top diagram and added table.
Revised content
