CPM2A/CPM2C Communications Functions
1:1 Link Master
CPM2C CPU Unit
CPM2C-CN111
(0.1 m)
CS1W-CN118
(0.1 m)
CPM2C-CIF01-V1
CPM2C-CIF11
OMRON PC (CQM1, CPM1, CPM1A, CPM2A,
SRM1(-V2), C200HS, or C200HX/HG/HE)
LR00
Write
LR07
LR08
Read
LR15
Note Even though the peripheral port on the CPM2C-CIF01-V1 can output RS-232C, this port cannot be used for
one-to-one link communications.
RS-232C port (D-sub 9-pin)
Connecting Cable
XW2Z-200T (2 m)
XW2Z-500T (5 m)
Master
Link bits
Write
area
Read
area
RS-232C port (D-sub 9-pin)
CPM2C-CN111 (0.1 m)
CS1W-CN118 (0.1 m)
CPM2C-CIF01-V1
CPM2C-CIF11
OMRON PC (CQM1, CPM1, CPM1A, CPM2A,
SRM1(-V2), C200HS, or C200HX/HG/HE)
Slave
Link bits
LR00
Read
area
LR07
LR08
Write
area
LR15
Section 4-3
1:1 Link Slave
CPM2C CPU Unit
Read
Write
265
