SRM1(-V2) Cycle Time and I/O Response Time

8-3-6 SRM1(-V2) Instruction Execution Times

Basic Instructions
Code Mnemonic ON execution
time ( s) i
--- LD 0.97
--- LD NOT 0.97
--- AND 0.77
--- AND NOT
--- OR 0.78
--- OR NOT
--- AND LD 0.39
--- OR LD
--- OUT 2.2
--- OUT NOT
--- SET 2.7
--- RSET 2.8
--- TIM 5.7
--- CNT 6.6
Special Instructions and Expansion Instructions
Code Mnemonic ON execution
time ( s)
00 NOP 0.20
01 END 4.8
02 IL 2.5
03 ILC 1.9
04 JMP 2.2
05 JME 2.5
06 FAL 18.4
07 FALS 3.6
08 STEP 10.7
09 SNXT 5.9
10 SFT
14.5
21.0
49.1
11 KEEP 3.0
12 CNTR
14.8
23.2
13 DIFU 6.7
Online editing:
Interrupts will be masked for a maximum of 600 ms (i.e.: editing DM 6144 to
DM 6655) when online editing is executed during operation. In addition, the
system processing may have to wait for a maximum of 170 s during this
processing.
The following table lists the execution times for SRM1(-V2) instructions.
Conditions (Top: min.; bottom: max.) (
( )
Any y
Any
Any
Constant for SV
:DM for SV
Constant for SV
:DM for SV
Conditions (Top: min.; bottom: max.)
Any y
With 1-word shift register
With 10-word shift register
With 100-word shift register
Any
Constant for SV
:DM for SV
Any y
p ; )
Section
OFF execution time ( s)
RSET IL JMP
---
---
---
9.3 9.1 3.5
17.4 17.2 3.5
8.0 3.6 3.8
16.3 3.6 3.8
OFF execution time ( s)
1.4
1.9
1.3
2.5
2.9
2.9
9.0
4.1
Reset IL JMP
11.0 1.4 1.4
14.9 1.4 1.4
30.8 1.4 1.4
Reset IL JMP
3.4 1.6 1.7
Reset IL JMP
9.1 6.6 6.5
Shift IL JMP
5.8 5.2 1.3
