Synchronized Pulse Control (CPM2A/CPM2C Only)

2-7

Synchronized Pulse Control (CPM2A/CPM2C Only)

Pulse input 00000
or 00001
Pulse output 01000 or 01001
(single-phase output)
Item
Input p 00000
number b
00001
Input method
Input frequency range
Output
01000
number (See number (See
01001
note 3.)
Output method
Output frequency range
Frequency ratio
Synchronized control cycle
134
By combining the CPM2A/CPM2C's high-speed counter function with the pulse
output function, the output pulse frequency can be controlled as a specified mul-
tiple of the input pulse frequency.
Note A CPU Unit with transistor outputs is required in order to use synchronized pulse
control, i.e., either a CPM2A-jjCDT-D or CPM2A-jjCDT1-D.
The following diagram shows the configuration for a CPM2A, but the configura-
tion for a CPM2C is identical.
Counter input
Differential phase
input mode
Phase-A input
Phase-B input
Differential phase
input (4X)
10 to 500 Hz (accuracy 1 Hz)
20 Hz to 1 kHz (accuracy 1 Hz)
300 Hz to 20 kHz (accuracy 25 Hz) (See note 2.)
Pulse output 0
Pulse output 1
Single-phase output
10 Hz to 10 kHz (accuracy 10 Hz)
1% to 1,000% (Can be specified in units of 1%.)
10 ms
Note 1. Can be used as an ordinary input.
2. When 10 kHz or less, then the accuracy is 10 Hz.
3. Either can be selected as the output number, using SYNC(––).
Main motor
Motor
driver
Input mode
Pulse + direction Up/down pulse
input mode input mode
Count input CW input
Direction input CCW input
Single-phase input Single-phase input
Section 2-7
Rotary encoder
Increment mode
Count input
(See note 1.)
Single-phase input
