CPM2A/CPM2C Interrupt Functions
Procedure for Using Interrupt Inputs
Set the interrupt input number.
Wire the inputs.
PC Setup (DM 6628)
Create a ladder diagram program.
The following table shows the relationships between interrupt inputs and the
CPM2A/CPM2C PC's other functions.
Function
Synchronized pulse control
Interrupt inputs
Interval timer interrupts
High-speed counters
Interrupt inputs (counter mode)
Pulse outputs
Quick-response inputs
Input time constant
Clock
Note 1. The same input number (from 00003 to 00006) cannot be used for more
than one of the following functions: interrupt inputs, interrupt inputs (counter
mode), or quick-response inputs.
2. When inputs 00003 to 00006 are set for use as interrupt inputs (counter
mode), the input time constants for the relevant inputs are disabled. The in-
put time constants remain in effect, however, for the values for refreshing
the relevant input relay area.
Input numbers: 00003 to 00006 (See note.)
Use as interrupt inputs (interrupt input mode or counter mode)
INT(89): For masking and unmasking interrupt inputs.
SBN(92) and RET(93): For creating interrupt subroutines.
Section
Interrupt inputs (counter mode)
Can be used simultaneously.
See note 1.
Can be used simultaneously.
Can be used simultaneously.
See note 1.
Can be used simultaneously.
See note 1.
See note 2.
Can be used simultaneously.
