Northern Telecom NAC Installation Manual page 53

3-28 Hardware installation
Table 3-4 (continued)
Internal input/output cables
ENG code
NT7D56AC
NT7D57AA
NT8D46AA
553-4011-110 Standard 1.0 November 1994
Application
VME SCSI 2 x 25
extension connector at
cable. Extends P2 and
SCSI from P2 MVME712AM/
adapter to the M, 50 Telco at
external SCSI MSU.
port via 712M
and to
connector at
MSU
Carries I/O 64 pin DIN
from ISI and connectors
ICC circuit (flat ribbon)
cards to their
transition
modules. (For
MVME712M)
XSM cable. 40 pin
carries signals
to the XSM
from the
power monitor
PCB
Cable and
connector
style
P2 adapter
(J3)
MVME332XT
(P2)
Power monitor
board (J1, J2)
—end—
From
External SCSI
port MSU (P3)
NT6D51AA
(P2)
Backplane of
module below
or XSM or
AEM below
To
