4-74 Peripheral devices
Procedure 4-11
Configuring the Ven-Tel 9600 Plus dial-up supervisor modem—remote end
Step Action
1 Open the modem and ensure that the
switch settings are correct. Compare
them with the correct settings in Figure
4-26.
2 Connect a workstation to the modem
with a straight through NT1R03Dx or
NT1R03Ex cable.
3 Connect the workstation and the
modem to their power sources. Make
sure the modem is connected to the
telephone system with an RJ-11
cable/connector.
4 Power up the workstation and the
modem.
5 Enter the following commands,
pressing {ENTER} after each
command.
at&f
ats2=128
at&c1
at&d2
atv1
atx1
ats0=1
atq0
ate0
553-4011-110 Standard 1.0 November 1994
Response
OK
OK
OK
OK
OK
OK
OK
OK
OK
—continued—
