Northern Telecom Meridian Meridian 1 Installation Manual

Application equipment module
Hide thumbs Also See for Meridian Meridian 1:
Table of Contents

Advertisement

Quick Links

Download this manual
Meridian 1
Application Equipment Module
Installation guide
Publication number:
Document Status:
Date:
Copyright
Northern Telecom 1991, 1992, 1993
All rights reserved.
Information is subject to change without notice. Northern Telecom reserves the right to make changes in
design or components as progress in engineering and manufacturing may warrant.
Meridian 1 and SL-1 are trademarks of Northern Telecom. UNIX is a trademark of AT&T. Motorola is a
trademark of the Motorola Corporation. MVME products are trademarked by the Motorola Corporation.
553-3201-200
Standard 3.0
April 1993
Application Equipment Module Installation guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Meridian Meridian 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Telecom Meridian Meridian 1

Summary of Contents for Northern Telecom Meridian Meridian 1

  • Page 1 Meridian 1 Application Equipment Module Installation guide Publication number: 553-3201-200 Document Status: Standard 3.0 Date: April 1993 Copyright Northern Telecom 1991, 1992, 1993 All rights reserved. Information is subject to change without notice. Northern Telecom reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant.

  • Page 2: Table Of Contents

    Contents Overview 1 AEM components 2 Stand-alone components 3 Pedestal 3 Top cap 3 Temperature requirements 4 Equipment handling precautions 5 Installing a stand-alone AEM 7 Unpack and level the AEM column 7 Power connections (ac) 9 Power connections (dc) 13 Alarm connections 22 Alarm connections with Meridian 1 systems 22 Alarm connections with ST or RT systems 25...
  • Page 3 ii Contents Removing an AEM 53 Ordering 55 Ordering information 55 Component failure rates 56 Glossary 57 Index 59 List of figures Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Figure 6 Figure 7 Figure 8 Figure 9 Figure 10 Figure 11 Figure 12...

  • Page 4: List Of Procedures

    Figure 21 Module-to-module power and system monitor connections 44 Figure 22 Module mounting bolts 45 Figure 23 Module positioning guides 45 Figure 24 Module power harness power connector 48 Figure 25 System monitor cable at connector J2 48 Figure 26 Removing the air exhaust grill 49 Figure 27 Cable well for wiring 50...
  • Page 5 iv Contents Table 7 Table 8 Table 9 Table 10 Table 11 Table 12 553-3201-200 Standard 1.0 April 1993 NT8D22 switch settings (set as master) for operation with RT 31 NT8D22 switch settings (set as master) for operation with RT 33 NT8D22 switch settings (set as master) for operation with RT 36 NT8D22 switch settings (set as master) for...

  • Page 6: Overview

    Overview Application Module hardware is based on Meridian 1 modular packaging. The basic unit of the modular package is the Universal Equipment Module (UEM), which is a modular, self-contained hardware cabinet that houses a card cage with a power supply, backplane, circuit cards, and other basic equipment.

  • Page 7: Aem Components

    2 Overview Meridian SL-1 systems (upgraded) capable of operating on Generic X11 Release 16, or later, software. An individual AEM can be placed in a column with other Meridian 1 modules in system options 21, 51, 61 or 71. This document explains how to install a stand-alone AEM and add an AEM to a Meridian 1 column.

  • Page 8: Stand-Alone Components

    Stand-alone components A stand-alone configuration consists of a pedestal, an AEM, and a top cap. Pedestal The pedestal houses a blower unit, an air filter, and the Power Distribution Unit (PDU). The PDU, which distributes power to the entire column, contains the field wiring terminal block, the main circuit breaker (or breakers) for the column, and a slot that houses the system monitor.

  • Page 9: Temperature Requirements

    4 Overview Temperature requirements The recommended ambient temperature differs depending in which tier that the AEM is placed. The following is the maximum ambient temperature for each operating tier: 1st tier: 35 degrees C (95 degrees F) 2nd tier: 30 degrees C (86 degrees F) 3rd tier: 25 degrees C (77 degrees F) 4th tier: 20 degrees C (68 degrees F) The recommended ambient temperature range for an AEM is:...

  • Page 10: Equipment Handling Precautions

    Equipment handling precautions To avoid personal injury and equipment damage, read the following guidelines before handling equipment. Use the following guidelines to handle circuit cards: Do not unpack or handle cards near electric motors, transformers, or similar machinery. Handle cards by the card stiffeners and edges only. Do not touch the contacts or components.

  • Page 11: Figure 2 Static Discharge Points

    6 Overview Figure 2xxx Static discharge points Wrist strap connection point 553-3201-200 Standard 1.0 April 1993 CAUTION Equipment damage To avoid damage from static discharge, wear an antistatic wrist strap when you work on AEM equipment. If a wrist strap is not available, regularly touch one of the bare metal strips in the AEM.

  • Page 12: Installing A Stand-Alone Aem

    Installing a stand-alone AEM For proper installation, perform the steps in the following procedures in the order given. Unpack and level the AEM column Remove the AEM column from the shipping pallet; follow the unpacking instructions that come with the packaging material. Remove the front and rear covers from the AEM: Remove the front and rear grills from the pedestal (see Figure 4).

  • Page 13: Figure 3 Locking Latches On The Aem

    8 Installing a stand-alone AEM Note 2: If the column is to be bolted to the floor for earthquake bracing, follow the procedure for earthquake bracing in System installation procedures (553-3001-210). Go to the procedure for “Power connections (ac)” or “Power connections (dc)”...

  • Page 14: Power Connections (Ac)

    Power connections (ac) One IG-L6-30 or L6-30 receptacle must be within 2.4 m (8 ft) of the pedestal. Instead of using the power plug provided, you can hard-wire the PDU to the power source. In this case, you should use #10 AWG conductors routed through 3/4-inch conduit.

  • Page 15: Figure 5 Pdu Connections

    10 Installing a stand-alone AEM Figure 5xxx PDU connections Connect the safety ground wire. Use insulated ground wire for system grounding. For a direct connection, connect a #6 AWG wire from the ground source in the service panel to a ground lug on the pedestal of the AEM column.
  • Page 16 Figure 6xxx Meridian 1/AEM column daisy chain connection From ground source Measure the resistance between the ground pin on the power plug and the ground terminal on the power outlet. The resistance should be zero ohms. If the resistance is greater than .5 ohms, check the power outlet ground and safety ground connections.
  • Page 17 12 Installing a stand-alone AEM Figure 7xxx AEM Logic return connection-LRTN/GND common connection for stand-alone column Figure 8xxx AEM Logic return connection-LRTN isolated star connection for a multi-column row 553-3201-200 Standard 1.0 April 1993 J3 J6 J5 J4 Power distribution unit J3 J6 J5 J4 Power distribution unit...

  • Page 18: Power Connections (Dc)

    Power connections (dc) A stand-alone AEM column can be connected to the dc power plant used with the Meridian 1 system. Depending on the distances between columns and the service panel, you may run safety ground wiring independently from the AEM column to the service panel, or you may daisy-chain the safety ground wiring between the AEM column and the Meridian 1.
  • Page 19 14 Installing a stand-alone AEM Table 1xxx Pedestal wire gauge requirements with two 30-amp 48 V dc feeds (see Note 1) Length Single conduit #8 AWG 0 - 3 m (10 ft) 0 - 6 m (20 ft) 0 - 9 m (30 ft) 0 - 12 m (40 ft) 0 - 15 m (50 ft) 0 - 18 m (60 ft)

  • Page 20: Figure 9 Direct Wiring Connection-Meridian 1 To Aem

    Procedure 2xxx Power connections (dc) Connect the safety ground wire. Use insulated ground wire for system grounding. For a direct connection, connect a #6 AWG wire from the ground source in the service panel to a ground lug on the pedestal of the AEM column.

  • Page 21: Figure 10 Backplane Cover

    16 Installing a stand-alone AEM Remove the backplane cover on the I/O assembly in the AEM above the pedestal, refer to Figure 10. Disconnect the power plug (J1) and system monitor ribbon cable to the AEM. Loosen the retaining screws that secure the PDU. If required, install a junction box near the pedestal of the AEM column.
  • Page 22 Connect red BAT wires from the power equipment to BAT connections on TB1 in the pedestal. Connections at the power equipment: For an NT6D82, connect wires to the first four circuit breakers in the main control/distribution panel (see Figure 11). (If one wire feeds two modules, connect only the first two breakers.) For a QBL12, connect wires to the first four available output connections on the -48V terminal panel (see Figure 12).
  • Page 23 18 Installing a stand-alone AEM Connect LRTN wiring (orange or white #8 AWG) from the power equipment to LRTN on TB1 in the pedestal: For an NT6D82, connect the wire to the ground bus/LRE. For a QBL12, connect the wire to the LRE. For a QBL15, connect the wire to the positive bus.

  • Page 24: Figure 11 Pedestal To Nt6D82 Connections

    Figure 11xxx Pedestal to NT6D82 connections NT6D82 power plant distribution panel Ground busbar/ LRE Column # 1 Note 1 Cabling in conduit between pedestal and NT6D82 To CB0 (module 0) and CB4 (blower) To CB1 (module 1) BAT0 BAT1 Note 1: Either connecting bar or LVD contacts Note 2: Do not connect trip lead if LVD option is installed.

  • Page 25: Figure 12 Pedestal To Qbl12 Or Qca13 Connections

    20 Installing a stand-alone AEM Figure 12 Pedestal to QBL12 or QCA13 connections To Logic Return Equalizer/Ground Window To CB0 (module 0) and CB5 (blower) BAT0 553-3201-200 Standard 1.0 April 1993 -48 V Terminal Panel 13 14 15 16 17 18 19 20 21 22 23 24 F1 F2 F3 F4 F5 F6 F7 F8 F13 F14 F15 F16 F17 F18 F19F20 F21F22F23 F24 Fuse Panel...

  • Page 26: Figure 13 Pedestal To Qbl15 Connections

    Figure 13 Pedestal to QBL15 connections Black wires Orange wire Note: one 30A feed per two modules Part of QBL15 distribution box GRD POS (+) positive bus DISCHARGE Cabling in conduit to pedestal Red wires To CB0 (module 0) To CB2 and CB5 (module 2) (blower)

  • Page 27: Alarm Connections

    22 Installing a stand-alone AEM Alarm connections When you add a stand-alone AEM to a Meridian 1, you must extend alarm cables from the AEM pedestal to the existing system as described in the following procedures. Alarm connections with Meridian 1 systems Use this procedure to configure and connect the NT8D22 system monitor in an AEM column that is connected to other Meridian 1 columns.
  • Page 28 Set all circuit breakers in the rear of the AEM pedestal to OFF (down), then connect the AEM column to the power supply. See the Application Module installation and upgrade guide (553-3201-210) for instructions on installing the Application Module and powering up the column. Application Equipment Module Installation guide Installing a stand-alone AEM 23...
  • Page 29 24 Installing a stand-alone AEM Table 3xxx SW2 positions 3 - 8-unit number for the slave Slave no. Switch position 553-3201-200 Standard 1.0 April 1993 Slave no. Switch position...

  • Page 30: Alarm Connections With St Or Rt Systems

    Alarm connections with ST or RT systems Table 4 lists the hardware required for alarm connections between an AEM column and ST or RT systems. If the AEM column is connected to a Power Fail Transfer Unit (PFTU) or you want an external alarm (such as a light or bell) for the AEM column, connect the system monitor to the main distribution frame (MDF).

  • Page 31: St System With A Qca136 Cabinet

    26 Installing a stand-alone AEM ST system with a QCA136 cabinet Use this procedure to configure and connect the NT8D22 system monitor in an AEM column that is connected to a Meridian SL-1 ST equipped with a QCA136 cabinet. Refer to Figure 14 during this procedure. Note: If you are not making alarm connections to the MDF, skip steps 3 through 6 and directly install connector P1 of the NT8D46AY cable into connector J3 of the system monitor.
  • Page 32 Remove the QCA136 rear panels and the EMI back panel. 10 Install the QCAD309 cable and the filter connector (P0678258) according to ST installation procedures (553-2431-210). 11 Connect P2 of the NT8D46AY cable into the filter connector at the bottom rear of the QCA136 cabinet. 12 Reinstall the QCA136 EMI back panel and the rear panels.

  • Page 33: St System With Qca136 And Qca137 Cabinets

    28 Installing a stand-alone AEM ST system with QCA136 and QCA137 cabinets Use this procedure to configure and connect the NT8D22 system monitor in an AEM column that is connected to a Meridian SL-1 ST equipped with QCA136 and QCA137 cabinets. Refer to Figure 15 during this procedure. Note: If you are not making alarm connections to the MDF, skip steps 3 through 6 and directly install connector P1 of the NT8D46BE cable into connector J3 of the system monitor.
  • Page 34 Remove the rear panels and EMI back panels from the QCA136 and QCA137. 10 Install connector J1 of the NT8D46BM cable into connector AL1 (P0678258 Filter Connector) at the bottom rear of the QCA136 cabinet. 11 Install connector J1 of the NT8D46BE cable into connector P1 of the NT8D46BM cable.
  • Page 35 30 Installing a stand-alone AEM Figure 15xxx Alarm connections to ST with QCA136 and QCA137 cabinets existing harness QCA137 AEM column J3 on system monitor * NT8D46BF and NT8D46BH are used only if connections to the MDF are required. 553-3201-200 Standard 1.0 April 1993 NT8D46BC NT8D46BE NT8D46BH*...

  • Page 36: Rt System With A Qca147 Cabinet

    RT system with a QCA147 cabinet Use this procedure to configure and connect the NT8D22 system monitor in an AEM column that is connected to a Meridian SL-1 RT equipped with a QCA147 cabinet. Refer to Figure 16 during this procedure. Note: If you are not making alarm connections to the MDF, skip steps 3 through 6 and directly install connector P1 of the NT8D46AY cable into connector J3 of the system monitor.
  • Page 37 32 Installing a stand-alone AEM Remove the QCA147 rear panels and EMI back panel. 10 Install connector P2 of the NT8D46AY cable into connector AL1 (P0678258 Filter Connector) at the bottom rear of the QCA147 cabinet. 11 Remove the QPF37A Alarm Adapter Plug. 12 Reinstall the QCA147 EMI back panel and rear panels.

  • Page 38: Rt System With Qca147 And Qca137 Cabinets

    RT system with QCA147 and QCA137 cabinets Use this procedure to configure and connect the NT8D22 system monitor in an AEM column that is connected to a Meridian SL-1 RT equipped with QCA147 and QCA137 cabinets. Refer to Figure 17 during this procedure. Note: If you are not making alarm connections to the MDF, skip steps 3 through 6 and directly install connector P1 of the NT8D46CH cable into connector J3 of the system monitor.
  • Page 39 34 Installing a stand-alone AEM 10 Make sure the existing alarm cable between the QCA147 and QCA137 cabinets is installed. 11 Remove the QPF37A Alarm Adapter Plug. 12 Install connector J1 of the NT8D46CH cable into connector AL1 (P0678258 Filter Connector) at the bottom rear of the QCA147 cabinet. 13 Reinstall the QCA147 EMI back panel and the rear panels.
  • Page 40 Figure 17xxx Alarm connections to RT with QCA147 and QCA137 cabinets alarm cable QCA147 (QPF37A is removed) QCA137 * NT8D46BF and NT8D46BH are used only if connections to the MDF are required. existing NT8D46BF* harness NT8D46CH NT8D46BH* Application Equipment Module Installation guide Installing a stand-alone AEM 35 AEM column J3 on...

  • Page 41: Rt System With Qca147 And Two Qca137 Cabinets

    36 Installing a stand-alone AEM RT system with QCA147 and two QCA137 cabinets Use this procedure to configure and connect the NT8D22 system monitor in an AEM column that is connected to a Meridian SL-1 RT equipped with a QCA147 and two QCA137 cabinets. Refer to Figure 18 during this procedure.
  • Page 42 Power down the QCA147 cabinet. Remove the QCA147 rear panels and EMI back panel. 10 Remove the QPF37A Alarm Adapter Plug in the QCA147 cabinet. 11 Verify that the alarm cable is installed between the QCA147 and the first QCA137 cabinets. 12 Install connector J1 of the NT8D46BL cable into connector AL1 (P0678258 Filter Connector) of the QCA147 cabinet.
  • Page 43 38 Installing a stand-alone AEM Figure 18xxx Alarm connections to RT with QCA147 and two QCA137 cabinets existing harness QCA137 AEM column NT8D46BF* J3 on system monitor * NT8D46BF and NT8D46BH are used only if connections to the MDF are required. 553-3201-200 Standard 1.0 April 1993 existing harness...

  • Page 44: Alarm Connections With Nt Or Xt Systems

    Alarm connections with NT or XT systems Use this procedure to configure and connect the NT8D22 system monitor in the AEM column when QPC84 or QPC173 Power Monitors are used in a Meridian SL-1 NT or XT. Note: During this procedure, refer to Figure 19 if the SL-1 is equipped with a QPC84 Power Monitor.
  • Page 45 40 Installing a stand-alone AEM Locate a -48 V source at the MDF. Connect it to the MDF0-48 connection (green wire) on the NT8D46BH cable. At the MDF, locate the SYSLTIN (blue wire) and CE-SYSLT (white wire) connections on the NT8D46BH cable: Refer to the installation manual for the NT/XT and install an SDI port.
  • Page 46 Figure 19xxx NT8D22 System Monitor connections to a QPC84 Power Monitor P10 cables from connector J10 SYSLTOUT QPC84 CE-ALARM Power Monitor in CE cabinet port SDI port in CE cabinet RS-232 SDI cable CE-ALARM QPC84 Power Monitor in PE cabinet blue white V BL...

  • Page 47: Figure 20 Nt8D22 System Monitor Connections To A Qpc173 Power Monitor

    42 Installing a stand-alone AEM Figure 20 NT8D22 System Monitor connections to a QPC173 Power Monitor P10 cables from connector J10 SYSLTOUT QPC173 CE-ALARM Power Monitor in CE cabinet port SDI port in CE cabinet RS-232 SDI cable CE-ALARM QPC173 Power SYSTIN Monitor in...

  • Page 48: Adding An Aem To A Column

    Adding an AEM to a column An AEM can be added to a Meridian 1 column in one of three positions; a procedure is given for each: Adding an AEM to the base of a column Adding an AEM between two other modules Adding an AEM to the top of a column There are similarities in the three procedures.
  • Page 49 44 Adding an AEM to a column Figure 21xxx Module-to-module power and system monitor connections 553-3201-200 Standard 1.0 April 1993 Connector to (or Top Cap) Backplane cover Panel Cover Connector J1 (Connect to J2 of previous UEM or to System Monitor Power connector Backplane cover...
  • Page 50 Figure 22xxx Module mounting bolts Top UEM Figure 23xxx Module positioning guides Rear Application Equipment Module Installation guide Adding an AEM to a column 45 Mounting bolts Positioning guides Front Opening for cables...

  • Page 51: Adding An Aem To The Base Of A Column

    46 Adding an AEM to a column Adding an AEM to the base of a column Procedure 10xxx Adding an AEM to the base of a column Remove the rear grill on the pedestal and set all circuit breakers to OFF (down).

  • Page 52: Adding An Aem Between Two Other Modules

    Adding an AEM between two other modules Procedure 11xxx Adding an AEM between two other modules Remove the rear grill on the pedestal and set all circuit breakers to OFF (down). Remove the module that will be above the AEM: Position and secure modules: Connect the power and system monitor cables between modules: See the Application Module installation and upgrade guide...

  • Page 53: Adding An Aem To The Top Of A Column

    48 Adding an AEM to a column Adding an AEM to the top of a column Procedure 12xxx Add an AEM to the top of a column Remove the rear grill on the pedestal and set all circuit breakers to OFF (down).
  • Page 54 Remove the top cap and perforated panel: Pull forward on the clips underneath the front edge of each air exhaust grill on the top cap. Remove the front and rear grills as illustrated in Figure 26. Figure 26xxx Removing the air exhaust grill Air exhaust grill Use a 5/16”...
  • Page 55 50 Adding an AEM to a column Connect the power and system monitor cables between the AEM and the module below it: Install the perforated panel and top cap on the AEM: Figure 27xxx Cable well for wiring 553-3201-200 Standard 1.0 April 1993 Use a 9/16”...
  • Page 56 Reconnect power to the top cap: Connect the system monitor cable to J2 on the AEM backplane (as shown in Figure 25). Line up the alignment tab on the connector (as shown in Figure 28) and snap on the pin headers to position the connector correctly. Connect the brown power connector to the module power harness, ensuring that the latches are locked in.
  • Page 57 52 Adding an AEM to a column Figure 29xxx Top cap assembly 553-3201-200 Standard 1.0 April 1993 Mounting screws Top Cap Front of UEM Screw for LED bracket on perforated panel...

  • Page 58: Removing An Aem

    Removing an AEM The steps for removing an AEM from a column are basically the same as for installing the AEM. However, before you remove an AEM, you must power down and remove any equipped Application Modules as described in the Application Module diagnostic and maintenance guide (553-3201-510).
  • Page 59 54 Removing an AEM 553-3201-200 Standard 1.0 April 1993...

  • Page 60: Ordering

    Ordering Ordering information Table 11 lists field replaceable items for the AEM and the quantity required for operation. Table 11 Field-replaceable items Part number Description NT7D00AA Top cap, ac NT7D00BA Top cap, dc NT7D09AA Pedestal, dc NT7D10AA Power distribution unit, dc NT7D18AA Application Equipment Module, ac NT7D18AB...

  • Page 61: Component Failure Rates

    56 Ordering Component failure rates Failure rates for basic AEM components in terms of the number of expected failures in one million hours of operation are listed in Table 11. Table 12 Component failure rates Component NT7D18AA NT7D64AA NT7D64DC These failure rates should be used in conjunction with the spares planning section of Spares planning (553-3001-153).
