Procedure 8-1 (continued)
Software reinstallation or upgrade to a NAC 2 system
Step Installer's action and system's response
Assigned Displays:#; Printers:#
NAC Communication Port Assignment
Port
Card 2, Conn1A
Card 2, Conn1B
Card 2, Conn1C
Card 2, Conn2A
Card 2, Conn2B
Card 2, Conn2C
Card 2, Conn3A
Card 2, Conn3B
Card 3, Conn1A
Card 3, Conn1B
Card 3, Conn1C
Card 3, Conn2A
Card 3, Conn2B
Card 3, Conn2C
Card 3, Conn3A
Card 3, Conn3B
PF1 = Options F6 = Update default printers
To delete an existing assignment, move the cursor to the line on which the device is
located. Press {REMOVE} and the device is removed.
An arrow appears on the right-hand side of the pop-up menu if all of the devices
could not fit on to the screen. Use the up and down arrow keys to move through the
menu.
Select the desired device from the list presented. To enter a selection, either move
the cursor to the selection and press {RETURN}, or enter the corresponding selec-
tion number and press {RETURN}.
If an device name is ghosted, it cannot be selected.
Links
The Device field can use two different links to connect NAC to a Meridian MAX node:
Network Link and Remote Supervisor Login.
Network Administration Center (NAC) Installation Guide Product release 2
Software reinstallations and upgrades
Available Ports: #
Device
—continued—
Device
1.Network Link
Connect Baud Name/Comment
2.Remote Login
DISPLAYS
3.Reflection 4+ on PC
4.VT420 or Compatible
5.VT220 or Compatible
6.Unknown Display
PRINTERS
7. HP DeskJet
8. HP DeskJet 560C
9. HP LaserJet
10. HP PaintJet
11. HP RuggedWriter–Epson
12. HP RuggedWriter–PCL
13. DEC LA 195–Epson
