Page 1 Meridian, Meridian MAX, Meridian MAX - IPE, ACD, ACD-MAX, NAC, Meridian 1, and SL-1, are trademarks of Northern Telecom. Compaq is a trademark of Compaq Computer Corporation. DEC, VT220 and VT420 are trademarks of Digital Equipment Corporation.
Page 2: Publication History
Publication history November 1994 This document was issued as the Network Administration Center (NAC) 2 Installation Guide (NTP 553–4011–110) Standard 1.0. Network Administration Center (NAC) Installation Guide Product release 2...
Page 3: Table Of Contents
System reliability 1-5 Automatic backup 1-5 Power failure 1-5 Mean Time Between Failures (MTBF) 1-6 Supported printers 1-6 Supported workstations 1-7 Supported modems 1-7 Network Administration Center (NAC) Installation Guide Product release 2 AC/DC supply 1-5 Uninterrupted Power Supply (UPS) 1-6...
Page 4 A word about warranties 3-1 Hardware overview 3-2 Required equipment and materials 3-3 Application module (AM) 3-6 Upgrading from NAC 1 on the HP Vectra 3-7 NAC connectivity overview 3-7 MVME167-34 single board computer card 3-9 Transition cards 3-12 MVME712M 3-12...
Page 5 Remote diagnostic modems NetComm SmartModem M7F Racal VI2422PA 4-47 UDS 2440 4-49 Dial-up supervisor modems NetComm SmartModem M7F Racal VI2422PA 4-63 Network Administration Center (NAC) Installation Guide Product release 2 4-13 4-18 4-24 4-30 4-36 4-38 4-41 4-42 4-44 4-60...
Page 6 Ven-Tel 9600 Plus Racal VI2422PA Gandalf LDS 120E Develcon DS 511A Software installation overview A word about warranties NAC 2 hardware platform Software installation procedures New software installations Load new software release Software reinstallations and upgrades Installation upgrades Application upgrades...
Page 7 Loading a new release of NAC 2 software Software reinstallations and upgrades Software reinstallation or upgrade for a NAC 2 system Platform upgrades Platform upgrade from a NAC 1 system to a NAC 2 system Operating modes Changing the default language Training mode...
Page 8: About This Document
Meridian 1 and Meridian 1-ready systems, such as Meridian 1 SL-1 style cabinets that have been upgraded. Conventions The following conventions are used throughout the NAC document set: CALLS ANSWD Words in this type represent things that you see on your screen or on printed reports.
Page 9: Other Nac Documents
NAC Supervisor’s User Guide Italicized text represents references to other documents. For example: Refer to NAC Supervisor’s User Guide. Other NAC documents Additional information about NAC is contained in the following Northern Telecom documents: 553-4011-510 P0724352 Reference to other ACD documents...
Page 10 553-4001-024 553-4001-121 553-4001-821 553-4001-921 553-4001-004 553-4001-111 Network Administration Center (NAC) Installation Guide Product release 2 About this document xvii Meridian MAX 6 Overview Meridian MAX 6 Installation Upgrade Guide for Meridian MAX 3, 4, 4.6 and 5 Systems Meridian MAX 6 Platform Upgrade...
Page 11: Sample Screens
This is due to the different keyboards that can be used with the display terminal. Please refer to the “The NAC workstation” chapter for more information. 553-4011-110 Standard 1.0 November 1994...
Page 12: Introduction
Meridian MAX sites, referred to as nodes, to monitor and supervise all sites from one central location. NAC 2 runs on the application module (AM) platform. Refer to the “NAC hardware overview” section of this chapter for a list of the NAC hardware components.
Page 13: Installation Responsibilities
1-2 Introduction Installation responsibilities The NAC 2 installation responsibilities fall upon two main groups: Northern Telecom, and Northern Telecom representatives or Meridian 1 distributors. Northern Telecom The following installation procedures are performed by Northern Telecom. Procure the hardware and software required for this installation.
Page 14: Installation Process Overview
Installation process overview The NAC 2 installation process can be divided into hardware and software procedures. Hardware procedures The following list provides an overview to the hardware procedures available in this document. Site layout Upgrading from a Vectra Installing the application module...
Page 15: Nac Installation Checklist
Changing the NAC system time NAC installation checklist The “NAC installation checklist” chapter lists all of the steps to be followed while installing a new NAC 2 system. Each step should be performed only if all of the following conditions are met. Refer to the “NAC installation checklist”...
Page 16: Installation Upgrade
Switch from Precutover Mode to Product Mode. Installation upgrade The following is a list of the steps required to perform a NAC 2 installation upgrade. Back up the system database from your existing system. Install the operating system and the NAC application software (customer-installed software).
Page 17: Uninterrupted Power Supply (Ups)
Mean Time Between Failures (MTBF) The MTBF value calculated for a NAC application module is 10,500 hours at 40 C (104 F). Table 1-1 list the major components of the NAC application module and their MTBF values. Table 1-1...
Page 18: Supported Workstations
Supported modems The following modems are supported for NAC 2. Gandalf 120E LDS Develcon DS 511A LDS Network Administration Center (NAC) Installation Guide Product release 2 in. or 5.25 in. disk drives can be used) DOS/MS DOS Version 5.0 or higher...
Page 19 1-8 Introduction NetComm SmartModem M7F Ven-Tel 2400 Plus II Ven-Tel 9600 Plus Racal VI2422PA UDS 2440 Note: Not all modems can be used for all functions. Refer to the “Peripheral devices” chapter, “Modems overview” section for more information. 553-4011-110 Standard 1.0 November 1994...
Page 20: Site Preparation
This chapter outlines the equipment requirements for your NAC 2 site. Power requirements Table 2-1 lists the power requirements for all of the hardware components used in the NAC 2. Ensure that your site can provide the needed power to run all of the equipment you require. Table 2-1...
Page 21 Table 2-1 (continued) NAC 2 power requirements Hardware Voltage Develcon DS511A 115 VAC NetComm 15 VAC SmartModem M7F UDS 2440 modem 115 VAC Ven-Tel 2400 Plus II 90–130 VAC and 9600 Plus II modems Racal VI2422PA 240, 220 or 115 VAC...
Page 22: Environmental Requirements
Environmental requirements Ensure that your site can maintain the required environmental conditions for the NAC 2 hardware before beginning the installation procedures. The following list details the environmental requirements for NAC 2 hardware. Operating temperature between 10 C–40 C (50 F–104 F) Non-operating temperature between –10 C–60 C (14 F–140 F)
Page 23: Site Layout
Locate the printers in conveniently accessible areas so that the network supervisors can obtain their reports. You may consider placing one printer near the network administrator and another printer near the NAC 2. Remember that the maximum range for the printer cable is 15 meters (50 feet).
Page 24: System Capacities
Note: One network link, one supervisor workstation, and one printer must be defined on your NAC 2 system at all times regardless of the system configuration. A remote login can be defined if needed but there is no minimum requirement.
Page 25: Printer Capacities
Network Links Remote Logins Workstations Printers Printer capacities Table 2-3 lists the print speed and the recommended maximum monthly usage values for each of the printers supported by NAC 2. Table 2-3 Printer capacities Printer RuggedWriter PaintJet 3630 LaserJet II...
Page 26: Hardware Installation
This chapter provides information and instructions on installing your NAC 2 system hardware. A word about warranties Read and understand the warranties issued for your NAC hardware and software. Each warranty details what you can and cannot do with the item warranted.
Page 27: Hardware Overview
Failure to power down the AM may cause unpredictable results. If your upgrade is performed on an existing system, follow the instructions contained in the “NAC power-down procedure” chapter. 553-4011-110 Standard 1.0 November 1994...
Page 28: Required Equipment And Materials
Required equipment and materials Table 3-1 lists the equipment and materials required for a NAC installation. Table 3-1 NAC installation equipment and material list Equipment NAC with console Cables Network Administration Center (NAC) Installation Guide Product release 2 Contents Motorola MVME712M transition card...
Page 29 3-4 Hardware installation Table 3-1 (continued) NAC installation’s equipment and material list Equipment Workstations (any combination) Reports Printer (any combination) Modems Software 553-4011-110 Standard 1.0 November 1994 Contents VDT-type (DEC VT420, DEC VT220 or HP700/32 or terminals which are 100% compatible)
Page 30 Table 3-1 (continued) NAC installation’s equipment and material list Equipment Documentation Miscellaneous equipment Supplies Network Administration Center (NAC) Installation Guide Product release 2 Contents P0724352 NAC 2 Supervisor’s User Guide P0802089 Meridian MAX 6 Supervisor’s User Guide P0802091 Meridian MAX 6 Supervisor’s Reference...
Page 31: Application Module (Am)
3-6 Hardware installation Application module (AM) Figure 3-1 shows the front view of NAC application module (AM). NAC can have one to five MVME332XT eight-channel asynchronous boards. Figure 3-1 NAC 2 application module (AM) Power supply 553-4011-110 Standard 1.0 November 1994...
Page 32: Upgrading From Nac 1 On The Hp Vectra
Upgrading from NAC 1 on the HP Vectra For system upgrades from NAC 1 on the HP Vectra platform to NAC 2 on the AM, an external SCSI port is provided. This port is used to connect an Archive 150 Mbyte tape drive for data downloading via a standard cartridge.
Page 33 Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Note: The NAC 2 module can also be in a stand-alone AEM module. 553-4011-110 Standard 1.0 November 1994 Network supervisor workstation Panel...
Page 34: Mvme167-34 Single Board Computer Card
MVME167-34 single board computer card The 32 Mbyte and 33 MHz MVME167-34 single board computer (SBC) card is the central processing unit of the NAC system. It is based on the MC68040 microprocessor. Eight light-emitting diodes (LEDs) and two buttons are located on the front of the MVME167-34 card.
Page 35 The buttons produce the following conditions and should not be pressed unless under the direction of Northern Telecom support personnel: ABORT: This button halts the NAC system. RESET: This button reinitializes the NAC system. The system performs a self test and then reboots. 553-4011-110 Standard 1.0 November 1994...
Page 36 Figure 3-3 LED locations for MVME167-34 card Network Administration Center (NAC) Installation Guide Product release 2 MVME 167-34A FAIL STAT RUN SCON LAN +12V SCSI VME ABORT RESET MVME167-34A FACEPLATE VIEW Hardware installation 3-11...
Page 37: Transition Cards
The MVME712M transition card is used as the interface between MVME167 family modules and the interconnect cables that attach to the I/O panel of the NAC. The features of the MVME712M card are one independent printer port and four 25-pin multiprotocol RS-232 serial ports.
Page 38 Figure 3-4 MVME712M transition card showing jumper switch settings Serial port Ethernet port Printer Port SCSI adapter Network Administration Center (NAC) Installation Guide Product release 2 Port 1 console Port 3 SDI link Modem interconnect (unused) Modem power Port 2...
Page 39: Mvme332Xt Eight-Channel Asynchronous Board
NAC module with four MVME332XT boards (32 ports) NAC module with five MVME332XT boards (40 ports) Each board in a NAC module has two banks of switches: a bank of eight and a bank of four. The set of eight switches has a unique setting for each card..
Page 40 HALT indicator: This yellow LED lights steadily when the processor has stopped. RUN indicator: This green LED lights almost continuously but flickers every few seconds when applications are running normally. Network Administration Center (NAC) Installation Guide Product release 2 Hardware installation 3-15...
Page 41 3-16 Hardware installation Figure 3-5 MVME332XT eight-channel asynchronous board Fail Halt LEDs Four-switch bank Board front 553-4011-110 Standard 1.0 November 1994 Board top Printer port (not used) Eight-switch bank...
Page 42: Nac Application Module Installation
NAC application module installation Once you have obtained your NAC system you must install the application module into your Application Equipment Module (AEM). The MVME167-34 card and MVME332XT eight-channel asynchronous boards are already installed in the application module. The power supply and mass storage unit (MSU) must then be installed in the application module.
Page 43 MVME332XT eight-channel asynchronous boards” subsection for more information on the installation of MVME332XT boards. 12 Connect your system console to the NAC using an NT7D61Ax cable. The DB-25 end connects to the workstation and the DB-9 end connects to the SYS CONS port on the I/O panel located at the rear of the Application Equipment module (AEM).
Page 44: Installing The Power Supply
Refer to the “Cables” section for for information on external cable connections. Installing the power supply The power for your NAC 2 application module is supplied by either an AC or DC power supply unit. Ensure the circuit breaker (CB) of the module in which you are installing the power supply is in the off position.
Page 45: Nac Application Module Label
3-20 Hardware installation NAC application module label Your NAC system is supplied with an application module label (P0800734) that contains a Meridian NAC and a Meridian MAX sticker. The Meridian NAC sticker should be adhered to the application module front panel, above the NT7D19SA label.
Page 46 Figure 3-6 Generic input/output connector panel NT6D51AA transition card connections MVME712M transition card connections Network Administration Center (NAC) Installation Guide Product release 2 Hardware installation 3-21 CARD 5 CARD 4 CARD 3 CARD 2 CONN 3 CONN 3 CONN 3...
Page 47: Input/Output Port Assignments
Input/output port assignments Five configurations of NAC 2 exist, based on the number of MVME332XT boards configured on the system. A NAC 2 system can be configured with one to five MVME332XT boards. Each MVME332XT, or I/O card, has a maximum of three ports that can be connected to multiport cables as seen in the “VME multiport cable”...
Page 48 Some connection types cannot be applied to some devices available. For example, the only connection type possible for a printer is direct connection. Ensure that you do not select an inappropriate connection type. Network Administration Center (NAC) Installation Guide Product release 2 Hardware installation 3-23...
Page 49 3-24 Hardware installation Table 3-3 NAC 2 communication port assignment sheet Card Port slot CARD 2, CONN 1 CARD 2, CONN 1 CARD 2, CONN 1 CARD 2, CONN 2 CARD 2, CONN 2 CARD 2, CONN 2 CARD 2, CONN 3...
Page 50 CARD 6, CONN 1 CARD 6, CONN 1 CARD 6, CONN 2 CARD 6, CONN 2 CARD 6, CONN 2 Network Administration Center (NAC) Installation Guide Product release 2 Cable Devices available SW / PRT / NL / RSL SW / PRT / NL / RSL...
Page 51 3-26 Hardware installation Table 3-3 (continued) NAC 2 communication port assignment sheet Card Port slot CARD 6, CONN 3 CARD 6, CONN 3 553-4011-110 Standard 1.0 November 1994 Cable Devices available SW / PRT / NL / RSL SW / PRT / NL / RSL —end—...
Page 52: Cables
Cables Internal input/output cables NAC 2 internal cables are used to interconnect all devices which are not connected through the VME bus backplane, but still require input/output capability. Table 3-4 lists all of the internal I/O cables available. Figure 3-7 shows a cabling schematic.
Page 53 3-28 Hardware installation Table 3-4 (continued) Internal input/output cables ENG code Application NT7D56AC VME SCSI extension cable. Extends SCSI from P2 adapter to the external SCSI port via 712M and to connector at NT7D57AA Carries I/O from ISI and ICC circuit cards to their transition modules.
Page 54 NT7D57AA VME P2 adapter to the 712M cable MLM–PSU P2 ADAPTER POWER SUPPLY 167–34 CPU card Network Administration Center (NAC) Installation Guide Product release 2 GENERIC INPUT/OUTPUT PANEL (Maximum of 5 NT6D51AA cards) NT7D56AC VME SCSI 712M Extension cable 332XT...
Page 55: Interconnect Input/Output Cables
3-30 Hardware installation Interconnect input/output cables NAC 2 interconnect cables exit from the rear of the transition modules/cards and terminate on the Application Equipment Module’s die-cast input/output panel via a custom input/output panel and radio-filtered connectors. Table 3-5 lists all of the interconnect I/O cables. Figure 3-7 shows cabling schematics, which identify the cables and devices which must be connected for a system.
Page 56 Carries input/output between the input/output connector panel (Card 2–6, Conn 1–3) and the NT6D51AA transition board. Network Administration Center (NAC) Installation Guide Product release 2 Cable and Connector style 25-pin (male) flat subminiature D-style to 25-pin (male) flat subminiature D-style —end—...
Page 57: External Input/Output Cables
3-32 Hardware installation External input/output cables NAC 2 external cables exit from the rear of the application module and terminate on the Application Equipment Module’s die-cast input/output panel via a custom input/output panel and radio-filtered connectors. Table 3-6 lists all of the external I/O cables. Figure 3-12 shows cabling schematics, which identify the cables and devices which must be connected for a system.
Page 58 NT7D99AA Connects as input/output between NAC 2 and dial-up modem, as well as, NAC 2 and LDS modem Network Administration Center (NAC) Installation Guide Product release 2 Hardware installation 3-33 Cable and connector style 25-pin (male) subminiature D-style connector to 9-pin...
Page 59 3-34 Hardware installation Figure 3-8 shows the cable arrangement for NT1R03Dx when supplying a connection between a modem and a peripheral device. Figure 3-8 Cabling arrangement—modem connection cable NT1R03Dx Male (DB–25) SCTE Note: Pins 1, 9–14, 16, 18, 19, 21–23 and 25 carry no signal and are not used with this cable. 553-4011-110 Standard 1.0 November 1994 DB–25 cable (NT1R03DB, 61 cm (2 ft))
Page 60 (DB–25) SCTE Note: Pins 1, 9-14, 16, 18, 19, 21-23 and 25 carry no signal and are not used with this cable. Network Administration Center (NAC) Installation Guide Product release 2 DB–25 cable (NT1R03EB, 62 cm (2 ft)) (NT1R03EC, 1.2 m (4 ft)) (NT1R03EF, 3 m (10 ft)) (NT1R03EP, 7.6 m (25 ft))
Page 61 3-36 Hardware installation Figure 3-10 shows the cable arrangement for NT7D61Ax when it is used for the system console or system external modem. Figure 3-10 Cabling arrangement—NAC 2 cable NT7D61Ax used for the system console, or a system external modem Male (DB-25) SHIELD 553-4011-110 Standard 1.0 November 1994...
Page 62 Figure 3-11 Cabling arrangement—modem connection cable NT7D99AA SHIELD Male (DB–25) Network Administration Center (NAC) Installation Guide Product release 2 DB-25 cable (NT7D99AA A0390645 2.2 m (7 feet)) Hardware installation 3-37 SHIELD 2 TD Male (DB–25)
Page 63 Card 1 Conn 4 NT7D58CA Ethernet SCSI TERMINATOR (A0379673) NT7D47DA Card 2 Conn 3 DB25 Card 2 Conn 2 NT7D95AA DB25 NT7D95AA DB25 Card 2 Conn 1 NAC 2 Meridian 1/SL–1 NT7D61Ax NT7D61Ax Unused port NT8D96AE NT8D96AE Input/output panels system console external modem...
Page 64: Vme Multiport Cable
VME multiport cable The VME multiport cable, shown in Figure 3-13, connects the NAC module with each peripheral in the system. Figure 3-13 VME multiport cable Connect to workstations/printers/network link Cable A Network Administration Center (NAC) Installation Guide Product release 2...
Page 65 An RS-232 straight-through cable with male DB-25 connectors can extend the range between a NAC and a peripheral device. The RS-232 must be less than 42 feet long, and must use all 25 pins. For greater distances, refer to the “Peripheral devices”...
Page 66 Table 3-7 VME multiport cable wiring From Network Administration Center (NAC) Installation Guide Product release 2 Hardware installation 3-41 Cable Signal name A, B, C SHIELD...
Page 67: Hardware Upgrades And Replacements
With each additional MVME332XT board, the number of available ports increases by increments of eight. The NAC 2 hardware platform can support between 8 and 40 ports, or one to five boards. It is less likely that you may need to replace a component of the system. If this is required, the upgrade instructions given in this section permit you to make the replacement.
Page 68: Adding Mvme332Xt Eight-Channel Asynchronous Boards
Adding MVME332XT eight-channel asynchronous boards Before inserting any additional cards into the NAC 2 system, ensure that each card’s switch settings match those given in Table 3-2. Shut down the NAC 2 software. Ensure that the I/O Port Reconfiguration on System Restart is enabled.
Page 69 3-44 Hardware installation Table 3-8 MVME332XT board slot placement Number of cards Take each new MVME332XT board from its packaging and check the switch settings. Refer to the “MVME332XT eight-channel asynchronous board” section of this chapter for this information. Carefully align the card with the black plastic guides found along the top and bottom of the VME card cage.
Page 70: Power Monitor Upgrades
Power monitor upgrades Before beginning this subprocedure using the Power Monitor Mounting Bracket Kit, NT7D18KA (A0405826), ensure that the NAC 2 software and the application modules (AM) contained in the Application Equipment Module (AEM) have been properly shut down. Remove the front and rear covers of the pedestal column located at the base of the column.
Page 71 3-46 Hardware installation Secure the existing terminal block to the new bracket using two hex head screws. 10 Connect the power monitor capacitor to the new bracket. Secure one end of the capacitor to the terminal block and the other to the mounting bracket.
Page 72: Replacing The Mvme167-34 Single Board Computer Card
Shut down the NAC 2 software. Refer to NAC 2 System Administration and Maintenance Guide (NTP 553-4011 - 510), “Maintenance and Administration programs: system running” chapter, “Shut down the system” section for instructions on shutting down your NAC 2 system.
Page 73 3-48 Hardware installation Replace the front and rear covers of the pedestal column located at the base of the column. Replace the two screws located at the upper left and right hand corners of the pedestal cover. Figure 3-14 MVME167-34 single board computer card Card Latches front...
Page 74: Configuring The Mvme167-34 Card
Shut down the NAC 2 software. Refer to NAC 2 System Administration and Maintenance Guide (NTP 553-4011-510), “Maintenance and administration programs: system running” chapter, “Shut down the system” section for instructions on shutting down your NAC system. Secure the NAC system for power down.
Page 75 3-50 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response If your card was preset in the factory, the following message appears. Autoboot in progress... To abort hit <BREAK> Press the {BREAK} key if your MVME167-34 card was preset in the factory. ––Break Detected––...
Page 76 Negate VMEbus SYSFAIL* Always [Y/N] ? Enter n to reject the Negate VMEbus SYSFAIL* Always prompt. The system displays the following prompt: Local SCSI Bus Reset on Debugger Startup [Y/N] = ? Network Administration Center (NAC) Installation Guide Product release 2 —continued— Hardware installation 3-51...
Page 77 3-52 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response Enter y to start up the local SCSI bus reset on the debugger. The system displays the following prompt: Local SCSI Bus Negotiations Type [A/S/N] Enter a to set the local SCSI bus negotiations type.
Page 78 The system displays the following prompt: ROM Boot Direct Starting Address = ? Enter FF800000. The system displays the following prompt: ROM Boot Direct Ending Address = ? Network Administration Center (NAC) Installation Guide Product release 2 —continued— Hardware installation 3-53...
Page 79 3-54 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response Enter FFBFFFFC. The system displays the following prompt: Network Auto Boot Enable [Y/N] = ? Enter n to disable the network auto boot. The system displays the following prompt: Network Auto Boot at power-up only [Y/N] = ? Enter y to enable the network auto boot at power-up only.
Page 80 Enter y to enable memory sizing for self-test diagnostics. The system displays the following prompt: Memory Size Starting Address = ? Enter 00000000. The system displays the following prompt: Memory Size Ending Address = ? Network Administration Center (NAC) Installation Guide Product release 2 —continued— Hardware installation 3-55...
Page 81 3-56 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response Enter 02000000. The system displays the following prompt: Base Address of Local Memory = ? Enter 00000000. The system displays the following prompt: Size of Local Memory Board #0 = ? Enter 02000000.
Page 82 The system displays the following prompt: Slave Address Translation Address #2 = ? Enter 00000000. The system displays the following prompt: Slave Address Translation Select #2 = ? Network Administration Center (NAC) Installation Guide Product release 2 —continued— Hardware installation 3-57...
Page 83 3-58 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response Enter 00000000. The system displays the following prompt: Slave Control #2 = ? Enter 01EF. The system displays the following prompt: Master Enable #1 [Y/N] = ? Enter y to enable the master address decoder #1.
Page 84 Enter 00000000. The system displays the following prompt: Master Control #3 = ? Enter 00. The system displays the following prompt: Master Enable #4 [Y/N] = ? Network Administration Center (NAC) Installation Guide Product release 2 —continued— Hardware installation 3-59...
Page 85 3-60 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response Enter n to not enable the master address decoder #3. The system displays the following prompt: Master Starting Address #4 = ? Enter 00000000. The system displays the following prompt: Master Ending Address #4 = ? Enter 00000000.
Page 86 Enter 00. The system displays the following prompt: PCC2 Vector Base = ? Enter 05. The system displays the following prompt: VMEC2 Vector Base #1 = ? Network Administration Center (NAC) Installation Guide Product release 2 —continued— Hardware installation 3-61...
Page 87 3-62 Hardware installation Procedure 3-1 (continued) Configuring the MVME167-34 card Step Installer’s action and system’s response Enter 06. The system displays the following prompt: VMEC2 Vector Base #2 = ? Enter 07. The system displays the following prompt: VMEC2 GCSR Group Base Address = ? Enter CC.
Page 88 Power down your system by flipping the power switch located to the left of the AEM to the OFF position. At this point, you may replace the MVME167 card or power on the system and install your NAC 2 software. Network Administration Center (NAC) Installation Guide Product release 2 Hardware installation 3-63 —end—...
Page 89: Nac 2 To Meridian Max
Refer to the “Peripheral devices” chapter, “Remote supervisor login modems” and “Network link modems” sections for more information. Your site’s layout may be different. A NAC 2 system can connect to a Meridian MAX 4.3x or 6.x or higher system in four ways. direct connection...
Page 90: Direct Connection
Direct connection If the NAC 2 system is within 50 feet of a Meridian MAX nodal system, then a direct connection can be used. Connect one DB-25 end of the NT7D99AA cable to the NAC octopus cable. Connect the other DB-25 end to the octopus cable at the Meridian MAX end.
Page 91: Limited Distance Connection
Two NT7D99AA cables are required. Connect the DB-25 end of the first NT7D99AA cable to the octopus cable at the NAC end. The other end of the cable is a DB-25 male connector, which is attached to the first limited distance modem.
Page 92: Cabling Arrangement
Figure 3-16 Connecting the NAC with a Meridian MAX node—limited distance connection Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î...
Page 93: T1 Connection
9600 through the Network Definition screen. The T1 network delay must be less than 0.5 second. Figure 3-17 shows a NAC 2 connected to a Meridian MAX via a T1 connection. Use either an NT7D58Ax or an NT7D99Ax cable to connect the T1 network to the Meridian MAX and NAC octopus cables.
Page 94 If the T1 port is configured as DCE and you are trying to connect the T1 port to the octopus cable’s network link port on the NAC 2 or Meridian MAX, use the modem cable NT7D99AA (Figure 3-11).
Page 95 3-70 Hardware installation Figure 3-18 Cabling arrangement—modem connection cable NT7D58Ax SHIELD Male DB-25 LRTN SCTE 553-4011-110 Standard 1.0 November 1994 DB–25 cable (NT7D58AB A0373938 2 feet) (NT7D58AD A0373939 6 feet) (NT7D58AF A0373940 10 feet) (NT7D58AL A0373941 20 feet) (NT7D58AT A0373942 35 feet) SHIELD Male...
Page 96: Nac 2 To Meridian Max
Dial-up connection This method of connection can be used if the NAC system is more than five miles from the octopus cable of the Meridian MAX nodal system. NAC 2 to Meridian MAX Two NT7D99AA modem cables and two dial-up modems are required to create a dial-up connection between the NAC to a Meridian MAX node.
Page 97: Peripheral Devices
Workstations are used by the network supervisors to control the operation of the NAC system. Workstations available for the NAC system can be separated into two categories: personal computers (PCs) and video display terminals (VDTs). Table 4-1 lists each type of workstation and the gender of its serial port.
Page 98: Personal Computer Workstations
PCs supported by the NAC 2 system are the IBM PS/2 30 and the Compaq Deskpro with: AT-style or enhanced-style keyboard 512 Kbytes of RAM Paradise EGA or VGA card with 256 Kbytes of memory either one 5.25 inch floppy disk drive, two floppy disk drives, or one floppy disk drive and hard disk (3.5 in.
Page 99: 3Pc With Hard Disk Running Reflection 4
DOS operating system disk in Drive A. When the PC boots up, insert the Reflection 4+ operating disk in Drive B, and select Drive B. Enter R4 to start the Reflection 4+ program. Network Administration Center (NAC) Installation Guide Product release 2...
Page 100: Video Display Terminal (Vdt) Workstation
Video display terminal (VDT) workstation Four types of video display terminal workstations are supported for NAC. DEC VT220 DEC VT420 (North American model) DEC VT420 (Worldwide model) HP 700/32 Note: To differentiate between the North American and Worldwide models of the VT420, view your workstation’s set-up directory. If there is a keyboard option, you are using the worldwide model.
Page 101: Dec Vt420 Or 100% Compatible (North American Model)
{ENTER} until the correct information is displayed. Complete these procedures before powering on NAC. Network Administration Center (NAC) Installation Guide Product release 2 Comm Printer...
Page 102 4-6 Peripheral devices Figure 4-2 DEC VT420 workstation (North American model) Version 1.3 or greater setup Set-Up Directory Global Display General Clear Display Clear Comm Default Screen Align Enable Sessions Disable Sessions Global Directory To Next Set-Up To Directory On Line S1 = Comm1 70 Hz Display Set-Up...
Page 103: Dec Vt420 Or 100% Compatible (Worldwide Model)
If any of the fields shown differ from those on your screen, cursor to the field and press {ENTER} until the correct information is displayed. Complete these procedures before powering on NAC. Network Administration Center (NAC) Installation Guide Product release 2...
Page 104 ,< and .> Keys Note: * This setting specifies the DEC setup language and does not affect the NAC screens. Change this setting to match the keyboard language you are using. *** This setting depends on the port you are using on the back of the terminal. Refer to your terminal guide for more information.
Page 105: Hp 700/32 Or 100% Compatible
NAC screens. *** This setting depends upon the version of terminal you are using. To save the Global settings, press the [SAVE MENU] key. Network Administration Center (NAC) Installation Guide Product release 2 Dark 15 Min 72 Hz U.S.
Page 106 Procedure 4-1 (continued) HP 700/32 workstation setup Step Action Ensure that the options match the following User settings: USER Smooth Scroll Cursor Type Cursor 2nd Message Line Message Line Status Line On Line Local Echo Auto Wrap Auto Linefeed Display Ctrl Codes Display Width Display Width Allowed Char Cell Height...
Page 107 Recv Pace Limited Transmit DSRI Break Duration Disconnect Delay Aux Printer Type To save the Port 1 settings, press the [SAVE MENU] key. Network Administration Center (NAC) Installation Guide Product release 2 VT320 VT220 8-Bit 8-Bit ISO 8859-1 Latin Numeric...
Page 108 Procedure 4-1 (continued) HP 700/32 workstation setup Step Action Ensure that the options match the following KeyBrd Menu settings: KEYBRD Menu Lock Key Kbd Lock Enable Save Tabs Auto Repeat Margin Bell Warning Bell Auto Answerback Answerback= Conceal Answerback Clear All Tabs Set 8 Column Tabs Tab Setting To save the Keybrd Menu settings, press the [SAVE MENU] key.
Page 109: Workstation Configuration
Workstation configuration As mentioned previously, two types of workstations are supported for NAC: VDTs and PCs. If you are using a workstation that was not previously configured as a NAC workstation, perform Procedure 4-2. Procedure 4-2 Workstation configuration Step Installer’s action and system’s response Press {CONTROL}{T} to begin this procedure.
Page 110 Procedure 4-2 (continued) Workstation configuration Step Installer’s action and system’s response The system continues. The terminal type for this port is unknown. Please choose a terminal type from the following list: DEC vt220 monochrome and compatibles DEC vt420 monochrome and compatibles PC running Reflection 4–PLUS terminal emulation Selection ––>...
Page 111 The transfer should take approximately 15 – 30 seconds. Please press <ENTER> to begin... Press {ENTER} to begin transferring the appropriate Reflection 4+ terminal configuration file from NAC to your workstation. Network Administration Center (NAC) Installation Guide Product release 2 —continued—...
Page 112 Procedure 4-2 (continued) Workstation configuration Step Installer’s action and system’s response If the transfer of the configuration is successful, the system displays the following prompts. If the transfer of the configuration is unsuccessful, go to Step 14. Transfer of configuration file was successful. From now on, use the following command when starting Reflection: R4 MERIDIAN.CFG If there are any key labels currently displayed at the bottom...
Page 113 The Supervisor Login screen appears after a few seconds. To exit Reflection 4+, log out from NAC. Wait until the login screen is completely redrawn. Enter {CONTROL}{ALT}{X}. The DOS prompt appears. If you wish to reconfigure your terminal while NAC is running, press {CONTROL}{T} simultaneously at anytime to display the configuration prompt.
Page 114: Printers
Printers There are ten types of printers that can be used by the NAC. DEC LA195 (does not support international languages) HP RuggedWriter HP LaserJet series II HP LaserJet series III HP LaserJet series 4 HP LaserJet series 4 Plus...
Page 115 Figure 4-4 Serial-parallel converter DIP switch settings Network Administration Center (NAC) Installation Guide Product release 2 CAUTION To avoid service interruptions Never use pencils or other graphite tools when changing the position of the DIP switches. Flakes of graphite can enter the switch and damage the printer.
Page 116: Dec La195
Epson-mode as configured in the VuePrint Menu System. Epson-mode does not support the international character set but provides faster printing of reports. Table 4-2 lists the correct system set-up for use with the NAC system. Figure 4-5 shows the correct DIP switch settings for use with the NAC system.
Page 117 Install 2: Tear off Paper out Auto CR Auto LF Copy mode Envelope Language Figure 4-5 DEC LA195 DIP switch settings Network Administration Center (NAC) Installation Guide Product release 2 Setting Italics Set 1 Enable English —end— Peripheral devices 4-21...
Page 118: Hp Ruggedwriter
PCL mode provides ISO Latin-1 international support as well as higher quality graphics. Epson mode does not support the international character set but provides faster printing of reports. Table 4-3 lists the correct DIP switch settings for use with the NAC system. Table 4-3 RuggedWriter option switch settings...
Page 119 Figure 4-6 RuggedWriter DIP switch settings Network Administration Center (NAC) Installation Guide Product release 2 RuggedWriter DIP switches Bank A Bank B Peripheral devices 4-23...
Page 120: Hp Laserjet Series Ii, Iii, 4 And 4 Plus
HP LaserJet series II, III, 4 and 4 Plus The LaserJet series II, III, 4 and 4 Plus are laser printers. Table 4-4 shows the correct option settings for the LaserJet series II. Table 4-5 shows the correct option settings for the LaserJet series III. Table 4-6 shows the correct option settings for the LaserJet series 4.
Page 121 Hold {Menu} key five seconds to view Configuration menu AUTO CONT = OFF I/O = SERIAL SERIAL = RS-232 BAUD RATE = 9600 ROBUST XON = ON DTR POLARITY = HI RET = DARK PAGEPROTECT = OFF Network Administration Center (NAC) Installation Guide Product release 2...
Page 122 Table 4-6 LaserJet series 4 printer option settings Press {Menu} key to view Printing menu COPIES = 1 PAPER = LETTER ORIENTATION = P FORM = 66 MANUAL FEED = OFF RET = DARK Press {Menu} key once to view PCL menu FONT SOURCE = I FONT NUMBER = 45 SYM SET = ISO L1...
Page 123 Press {Menu} key three times to view Configuration menu MP TRAY = CLASS LOCK = NONE CLR WARN = ON AUTO CONT = OFF DENSITY = 3 LOW TONER = CONT Network Administration Center (NAC) Installation Guide Product release 2 —continued—...
Page 124 Table 4-7 LaserJet series 4 Plus printer option settings (continued) Press {Menu} key four times to view Memory configura- tion menu IO BUFFER = AUTO Press {Menu} key five times to view Parallel menu HIGH SPEED = YES ADV FNCTNS = OFF Press {Menu} key six times to view Serial menu PACING = XON/XOFF BAUD RATE = 9600...
Page 125: Hp Paintjet 3630, Deskjet, Deskjet 500 And Deskjet 560C
See the “Serial-parallel converter” section for more details. Figure 4-7 HP PaintJet 3630, DeskJet, DeskJet 500 and DeskJet 560C DIP switch settings DOWN DOWN Network Administration Center (NAC) Installation Guide Product release 2 HP DeskJet, DeskJet 500 and DeskJet 560C DIP switches Bank A Bank B...
Page 126: Modems Overview
Supported modems There are a number of modems that can be used to connect a Meridian MAX system or peripheral device to the NAC. Table 4-8 lists each type of modem and the gender of its DB-25 serial port. Table 4-8 Modems—DB-25 serial port genders...
Page 127: Other Modems
Ven-Tel 9600 Plus A limited distance modem is used when peripheral devices are connected to the NAC through a direct connection. If a direct connection cannot be supported, a dial-up modem is used to connect the peripheral device or Meridian MAX to the NAC through the public service telephone network (PSTN).
Page 128 Table 4-10 Supported Hayes modem commands * This command is only used with the NetComm Smart- 553-4011-110 Standard 1.0 November 1994 Command AT&C1 AT&D0 AT&D2 AT&F Recall factory settings AT&W ATDS1 Dial stored number ATDS=1* Dial stored number ATDT... ATE0 ATH0 ATL0 ATQ0...
Page 129 Table 4-11 Supported modem responses Command Network Administration Center (NAC) Installation Guide Product release 2 Response RING CONNECT 1200 CONNECT 2400 CONNECT 4800 CONNECT 9600 CONNECT NO CARRIER MODEM ERROR NO DIAL TONE BUSY NO ANSWER...
Page 130: Modem Cables
4-34 Peripheral devices Modem cables Modems can be connected to the NAC using two modem cables: the NT7D99AA null modem cable and the NT7D61Ax cable. Figure 4-8 shows the cabling arrangement for the NT7D99AA cable for use with dial-up supervisor, remote supervisor login and network link.
Page 131 Cabling arrangement—modem connection cable NT7D61Ax for remote diagnostics Male (DB-25) SHIELD Network Administration Center (NAC) Installation Guide Product release 2 DB-25 to DB-9 cable (NT7D61AB A0374031 61 cm (2 feet)) (NT7D61AD A0374070 1.8 m (6 feet)) (NT7D61AF A0374071 3 m (10 feet)) (NT7D61AL A0374072 6.1 m (20 feet))
Page 132: Limited Distance Modem
Limited distance modem If you need more than 15 meters (50 feet) between the NAC and any peripheral, you need to use a limited-distance modem. The limited-distance modem must be self-powered. The added range depends on the modem you obtain. Limited-distance modems are recommended for use inside buildings only.
Page 133 The switch on the back of the modem should be set to the “normal” position. Figure 4-10 Gandalf LDS 120E limited distance modem hardware configuration Multiport I/O cable Female DB–25 Gandalf LDS120E Network Administration Center (NAC) Installation Guide Product release 2 Cable NT7D99AA Male DB–25 Twisted pairs Peripheral Cable NT7D99AA NT1R03Dx Male DB–25...
Page 134: Gandalf Lds 120E Modem Settings
Figure 4-11 Develcon DS 511A limited distance modem hardware configuration Multiport I/O cable Male DB–25 Female DB–25 Develcon DS 511A Gandalf LDS 120E modem settings The following settings are necessary for the Gandalf LDS 120E modem to be used: Termination: T (330 OHM) Internal Jumper Plugs: 4 connected Front Panel Push-button Switches: ALL OUT - TP - RL - DL - AL...
Page 135 Some peripherals connect to male DB-25 connectors and others connect to female DB-25 connectors. The creation of the straight-through DB-25 cable and the 2-pair twisted cable is the Network Administration Center (NAC) Installation Guide Product release 2 Switch setting OPEN (OFF)
Page 136 4-40 Peripheral devices responsibility of the user and it is the user’s responsibility to ensure that the correct connectors are attached. Connect one end of the modem cable NT7D99AA to the VME multiport cable. Connect the other end to the female DB-25 socket on the first Gandalf LDS 120E or Develcon DS 511A modem.
Page 137: Dial-Up Modems Overview
Remote diagnostics Dial-up supervisor Network link Remote Supervisor Login feature specific to the NAC option (see NAC 2 Supervisor’s User Guide (P0724352) for more information on this feature) The same brand of dial-up modem must be used for either purpose. Ensure that each modem connected to the network is properly set up for its purpose.
Page 138: Remote Diagnostic Modems
NetComm SmartModem M7F Racal VI2422PA UDS 2440 The cable between NAC I/O panel and the remote diagnostic modem is a DB-25 (male) to DB-9 (female) modem cable, NT7D61Ax. This cable is connected to the I/O panel at Card 1, Conn 2.
Page 139 Refer to your specific modem setups. Once this is done, disconnect the modem and reconnect it to the NAC. Figure 4-12 Connecting the remote diagnostics workstation with a NAC remote diagnostic modem Modem Telephone Over 5 miles...
Page 140: Netcomm Smartmodem M7F
To properly set up the NetComm modem for remote diagnostics, ensure the modem’s switch settings match those shown in Figure 4-13. The same switch settings should be used at both the remote end and the NAC end. Note: There are two buttons located on the front panel of the modem: Mode and Talk/Data.
Page 141 Connect the modem directly to the NAC generic I/O panel using an NT7D61Ax modem cable. Make sure the modem is connected to the telephone system with an RJ-11 cable/connector. Network Administration Center (NAC) Installation Guide Product release 2 Response —continued—...
Page 142 Power up the modem. 553-4011-110 Standard 1.0 November 1994 Response If your NAC system is powered up and fully functional, you should see the LED labelled “TR” light up on the front panel of the modem. If the “TR” LED does not light up, retry this procedure.
Page 143: Racal Vi2422Pa
Racal VI2422PA modem at the other end as well. Both modems must be set to the same speed. Figure 4-12 illustrates the connection between the NAC remote diagnostics port and a remote workstation using a Racal VI2422PA modem. Complete the steps in Procedure 4-4 to configure the Racal modem for remote diagnostics.
Page 144 Power down the workstation and the modem. Disconnect the workstation from the modem. Connect the modem directly to the NAC I/O panel using an NT7D61Ax (AM) modem cable. Make sure the modem is connected to the telephone system with an RJ-11 cable/connector.
Page 145: Uds 2440
If you want to configure the UDS 2440 modem for remote diagnostic support using the modem’s front panel buttons, perform Procedure 4-5. Network Administration Center (NAC) Installation Guide Product release 2 MR/RI WARNING – FOR CONTINUED...
Page 146 Step Configuration action and system response Connect the modem to a power source next to the NAC system. Ensure that the modem is not connected to the NAC system at this point. Position the power switch on the rear panel of the modem to ON.
Page 147 Press {NO}. FACTORY? Press {YES}. FACTORY 0? Press {YES}. LOADING (appears for one second) FACTORY? Press {NO}. SPKR OPTS? Press {NO}. TELE OPTS? Press {NO}. PIN OPTS? Press {NO}. MSG OPTS Network Administration Center (NAC) Installation Guide Product release 2 —continued—...
Page 148 Procedure 4-5 (continued) Configuring the UDS 2440 modem via the front panel for remote diagnostics Step Configuration action and system response Press {NO}. SECURITY? Press {NO}. DISC OPTS? Press {NO}. SREGS? Press {NO}. OPTIONS? Press {NO}. PROTOCOL? Press {NO}. If SAVE? appears go to Step 23, if not go to Step 24. Press {YES}.
Page 149 Press {YES}. RING = 001 Press {YES}. AUTO ANS? Press {NO}. DATA OPTS? Press {NO}. OPTIONS? Press {YES}. RESET? Press {NO}. FACTORY? Press {NO}. SPKR OPTS? Press {NO}. TELE OPTS? Network Administration Center (NAC) Installation Guide Product release 2 —continued—...
Page 150 Procedure 4-5 (continued) Configuring the UDS 2440 modem via the front panel for remote diagnostics Step Configuration action and system response Press {NO}. PIN OPTS? Press {YES}. DTR OPTS? Press {YES}. DTR OPTS 0 Press {NO}. dtr opt 1 Press {NO}. dtr opt 2 Press {NO}.
Page 151 Press {NO}. cd normal Press {YES}. CD OPTS? Press {NO}. CTS OPTS? Press {NO}. P 21 OPTS? Press {NO}. P 23 OPTS? Press {NO}. P 25 OPTS? Network Administration Center (NAC) Installation Guide Product release 2 —continued—...
Page 152 Procedure 4-5 (continued) Configuring the UDS 2440 modem via the front panel for remote diagnostics Step Configuration action and system response Press {NO}. PIN OPTS? Press {NO}. MSG OPTS Press {NO}. SECURITY? Press {NO}. DISC OPTS? Press {NO}. SREGS? Press {NO}. OPTIONS? Press {NO}.
Page 153 Make sure the modem is connected to the telephone system with an RJ-11 cable/connector. If your NAC system is powered up and fully functional, you should see the LED labelled “TR” light up on the front panel of the modem. If the “TR” LED does not light up, retry this procedure.
Page 154 Power down the workstation and the modem. Disconnect the workstation from the modem. Connect the modem directly to the NAC I/O panel using an NT7D61Ax modem cable. Make sure the modem is connected to the telephone system with an RJ-11 cable/connector.
Page 155 Step Action Power up the modem. Network Administration Center (NAC) Installation Guide Product release 2 Response If your NAC system is powered up and fully functional, you should see the LED labelled “TR” light up on the front panel of the modem.
Page 156: Dial-Up Supervisor Modems
DB-25 to DB-9 serial cable (male to female) A0268901. The cable between the NAC and the dial-up supervisor modem is a modem cable NT7D99AA. Figure 4-15 illustrates this connection. NAC automatically configures remote supervisor modems connected at the NAC end.
Page 157: Netcomm Smartmodem M7F
To properly set up the NetComm modem for dial-up supervisor, ensure the modem’s switch settings match those shown in Figure 4-16. The same switch settings should be used at both the remote end and the NAC end. NAC automatically configures remote supervisor modems connected at the NAC end.
Page 158 Use the Hayes AT command “atdt####” for touch-tone dialing and “atdp####” for pulse dialing to dial the required number. (where #### is the telephone number of the NAC modem) 553-4011-110 Standard 1.0 November 1994 Response...
Page 159: Racal Vi2422Pa
For example, a single network link could have a Racal modem at the NAC site and a Racal modem at the nodal Meridian MAX site. Both modems must be set to the same speed.
Page 160 1. Choose option 13 and set the value to 2. Use the Hayes AT command “atdt####” for touch-tone dialing and “atdp####” for pulse dialing to dial the required number. (where #### is the telephone number of the NAC modem) 553-4011-110 Standard 1.0 November 1994 Response...
Page 161: Network Administration Center (Nac) Installation Guide Product Release 2
Complete Procedure 4-9 to configure the UDS 2440 modem for dial-up supervisor. NAC automatically configures remote supervisor modems connected at the NAC end. The cable connecting the NAC AM’s VME multiport cable and the UDS 2440 modem is the modem cable NT7D99AA. Procedure 4-9 Configuring the UDS 2440 modem for dial-up supervisor—remote end...
Page 162 Use the Hayes AT command “atdt####” for touch-tone dialing and “atdp####” for pulse dialing to dial the required number. (where #### is the telephone number of the NAC modem) 553-4011-110 Standard 1.0 November 1994 Response —end—...
Page 163: Ven-Tel 2400 Plus Ii
Figure 4-18 Ven-Tel 2400 Plus II modem—rear view Figure 4-19 Ven-Tel 2400 Plus II modem—opening the modem Groove Network Administration Center (NAC) Installation Guide Product release 2 HS AA CD OH RD SD TMMR/EO MODEL 2400 PLUS II POWER RS 232/CIA...
Page 164 Line NAC automatically configures remote supervisor modems connected at the NAC end. The cable connecting the NAC AM’s VME multiport cable and the Ven-Tel 2400 Plus II modem is the modem cable NT7D99AA. To properly set up the Ven-Tel 2400 Plus II modem for use as a dial-up supervisor login modem, ensure the modem’s switch settings match those...
Page 165 Make sure the modem is connected to the telephone system with an RJ-11 cable/connector. Power up the workstation and the modem. Network Administration Center (NAC) Installation Guide Product release 2 Response —continued— Peripheral devices 4-69...
Page 166 Use the Hayes AT command “atdt####” for touch-tone dialing and “atdp####” for pulse dialing to dial the required number. (where #### is the telephone number of the NAC modem) 553-4011-110 Standard 1.0 November 1994 Response —end—...
Page 167 Figure 4-25 shows the switch locations. Figure 4-22 Ven-Tel 9600 Plus modem—front view Figure 4-23 Ven-Tel 9600 Plus modem—rear view Network Administration Center (NAC) Installation Guide Product release 2 HS AA CD OH RD SD TMMR/EO MODEL 9600 Plus POWER RS 232/CIA...
Page 168 4-72 Peripheral devices Figure 4-24 Ven-Tel 9600 Plus modem—opening the modem Groove Figure 4-25 Ven-Tel 9600 Plus modem—switch locations Line White and red indicator lights 553-4011-110 Standard 1.0 November 1994 Modem computer board Bottom RS 232/EIA Power socket cable socket Line EPROM EPROM...
Page 169 NAC automatically configures remote supervisor modems connected at the NAC end. The cable connecting the NAC AM’s VME multiport cable and the Ven-Tel 9600 Plus modem is the modem cable NT7D99AA. To properly set up the Ven-Tel 9600 Plus modem for use as a dial-up supervisor modem, ensure the modem’s switch settings match those shown...
Page 170 Procedure 4-11 Configuring the Ven-Tel 9600 Plus dial-up supervisor modem—remote end Step Action Open the modem and ensure that the switch settings are correct. Compare them with the correct settings in Figure 4-26. Connect a workstation to the modem with a straight through NT1R03Dx or NT1R03Ex cable.
Page 171 Use the Hayes AT command “atdt####” for touch-tone dialing and “atdp####” for pulse dialing to dial the required number. (where #### is the telephone number of the NAC modem) Network Administration Center (NAC) Installation Guide Product release 2 Response —end—...
Page 172: Ven-Tel 9600 Plus (With Power Pack Model # L5730-01)
To properly set up the NetComm modem for remote supervisor login, ensure the modem’s switch settings match those shown in Figure 4-27. The same switch settings should be used at both the remote end and the NAC end. Note: There are two buttons located on the front panel of the modem: Mode and Talk/Data.
Page 173: Uds 2440
No internal switch settings are required to configure the Racal VI2422PA modem for remote supervisor login. Refer to the “Dial-up supervisor modem” section, “Racal VI2422PA” subsection for more information. Network Administration Center (NAC) Installation Guide Product release 2 Peripheral devices 4-77...
Page 174: Gandalf Lds 120E
Gandalf LDS 120E The Gandalf LDS 120E can be used as a remote supervisor login or network link modem. Figure 4-29 illustrates the modems configuration as either a remote supervisor login or a network link. Figure 4-29 Gandalf LDS 120E limited distance modem hardware configuration for remote supervisor login or network link Multiport I/O cable...
Page 175 This lamp indicates that both Gandalf LDS 120E or Develcon DS 511A modems are active. Please note that these instructions may vary depending on the equipment used at your site. Network Administration Center (NAC) Installation Guide Product release 2 Switch setting OPEN (OFF) CLOSED (ON)
Page 176 4-80 Peripheral devices Some peripherals connect to male DB-25 connectors and others will connect to female DB-25 connectors. The creation of the straight-through DB-25 cable and the 2 pair twisted cable is the responsibility of the user and it is the user’s responsibility to ensure that the correct connectors are attached.
Page 177: Develcon Ds 511A
Develcon DS 511A limited distance modem hardware configuration for remote supervisor login or network link Multiport I/O cable Male DB–25 Female DB–25 Develcon DS 511A Network Administration Center (NAC) Installation Guide Product release 2 Cable NT7D99AA NT7D99AA Twisted Pairs Meridian MAX Cable Male DB–25...
Page 178: Network Link Modems
To properly set up the NetComm modem for network link, ensure the modem’s switch settings match those shown in Figure 4-31. The same switch settings should be used at both the remote end and the NAC end. Note: There are two buttons located on the front panel of the modem: Mode and Talk/Data.
Page 179 ####### must be replaced with the correct telephone number for the Meridian MAX node. at&w Power down the workstation and the modem. Disconnect the workstation from the modem. Network Administration Center (NAC) Installation Guide Product release 2 Response —continued—...
Page 180 Meridian MAX site is confirmed when the Carrier Detect (CD) LED remains constantly on. If your NAC system is powered up and fully functional, you should see the LED labelled “TR” light up on the front panel of the modem. If the “TR” LED does not light up, retry this procedure.
Page 181: Uds 2440
Power up the workstation and the modem. Enter the following commands on the workstation keyboard, pressing {ENTER} after each command. at&f at&d3 at&s1 at&c1 Network Administration Center (NAC) Installation Guide Product release 2 Response —continued—...
Page 182: Ven-Tel 2400 Plus Ii
Figure 4-32. 553-4011-110 Standard 1.0 November 1994 Response If your NAC system is powered up and fully functional, you should see the LED labelled “TR” light up on the front panel of the modem.
Page 183 Connect the workstation and the modem to their power sources. Power up the workstation and the modem. Enter the following commands, pressing {RETURN} after each command. at&f at&d0 Network Administration Center (NAC) Installation Guide Product release 2 Response —continued— Peripheral devices 4-87...
Page 184 Procedure 4-14 (continued) Configuring the Ven-Tel 2400 Plus II modem for network link Step Action at&c1 at\n1 at\g1 at\q1 at\x1 at\j1 at\c1 ats64=1 ats0=1 at&z1=t####### ####### must be replaced with the correct telephone number for the Meridian MAX node. atq1 ate0 The following command will not appear on the screen when you enter it.
Page 185 Make sure the modem is connected to the telephone system with an RJ-11 cable/connector. Power up the modem. Network Administration Center (NAC) Installation Guide Product release 2 Response The NAC modem will dial the Meridian MAX telephone number as recorded during Step 5.
Page 186: Ven-Tel 9600 Plus
Ven-Tel 9600 Plus To properly set up the Ven-Tel 9600 Plus modem for use as a network link, ensure that the modem’s switch settings match those shown in Figure 4-26, and follow the instructions given in Procedure 4-15. Make sure power pack model # L5730-01 is used. Procedure 4-15 Configuring the Ven-Tel 9600 Plus modem for network link Step...
Page 187 Connect the modem directly to the NAC using an NT7D99AA modem cable. Make sure the modem is connected to the telephone system with an RJ-11 cable/connector. Network Administration Center (NAC) Installation Guide Product release 2 Response NONE NONE NONE The NAC modem will dial the Meridian MAX telephone number as recorded during Step 5.
Page 188 Power up the modem. 553-4011-110 Standard 1.0 November 1994 Response If your NAC system is powered up and fully functional, you should see the LED labelled “TR” light up on the front panel of the modem. If the “TR” LED does not light up, retry this procedure.
Page 189: Racal Vi2422Pa
Power up the workstation and the modem. Enter the following commands, pressing {ENTER} after each command: at&f at*f0 at&zt####### ####### must be replaced with the correct telephone number for the Meridian MAX node. Network Administration Center (NAC) Installation Guide Product release 2 Response —continued—...
Page 190 Power down the workstation and the modem. Disconnect the workstation from the modem. Connect the modem directly to the NAC using an NT7D99AA modem cable. Make sure the modem is connected to the telephone system with an RJ-11 cable/connector.
Page 191: Gandalf Lds 120E
Develcon DS 511A The Develcon DS 511A modem can be used as as network link modem. Refer to the “Remote supervisor login modems” section, “Develcon DS 511A” subsection for more information. Network Administration Center (NAC) Installation Guide Product release 2...
Page 192: Software Installation Overview
NTP. If you find such a condition, contact your dealer or Northern Telecom service representative. Network Administration Center (NAC) Installation Guide Product release 2 CAUTION Understand your warranty...
Page 193: Nac 2 Hardware Platform
New software installations If your operation has never used a NAC system, you can only complete a NAC 2 new software installation. There are two types of new software installations—customer-installed or factory-installed.
Page 194: Application Upgrades
NAC 2 system. No hardware changes are required. Platform upgrades If you are currently using a NAC 1 system and are upgrading to a NAC 2 system, a platform upgrade must be completed, providing you have made the necessary hardware changes.
Page 195: Retained Port Assignments
For example, if a 32-port NAC 2 system was upgraded to a 24-port NAC 2 system, the port assignments for the first 24 ports would be retained from the previous NAC 2 system.
Page 196: Backups
Any data lost between when the backup was taken and when the failure occurs can sometimes be recovered (depending on the nature of the failure). Ensure that a backup tape is in the NAC tape drive for the midnight backup.
Page 197: Reentry Points
5-6 Software installation overview Reentry points NAC 2 software has four installation reentry points that can be used if a problem occurs during the software installation. If a software installation must be aborted at some point, the installation can be restarted from the last successfully completed section of the installation.
Page 198: Installation Tapes
Keep tapes away from excessive heat or electromagnetic radiation. Figure 5-1 shows the correct method for inserting a tape cassette into the tape drive of a NAC 2 system. Make sure the arrow on the label points towards the drive, and that the notch in the cassette tape is pointing down.
Page 199 Generic Operating System tape NAC Application tape To insert or remove a cassette tape from the NAC 2 module’s tape drive, the front panel may be removed for short periods of time. If you do not need to access the module shortly afterwards, make certain that the front panel is properly replaced.
Page 200 Application Equipment Module (AEM) remains reasonably constant, and within the operating temperature ranges of the equipment. Figure 5-1 Inserting a cassette into the tape drive of a NAC 2 system Installation tape Notch points down Write enabled Protected Note: If the cassette tape is incorrectly inserted into the tape drive, the tape automatically ejects.
Page 201 5-10 Software installation overview WARNING Entering numbers When entering a number in response to a prompt, use the upper row of keys (numbers) rather than the numeric keypad. If you want to use the numeric keypad, ensure that the keyboard indicator “NUM LOCK”...
Page 202: New Software Installations
To distinguish factory-installed software from customer-installed software, power up the NAC 2 module. If the console login prompt appears, then the system has factory-installed software. If the system does not boot up, it has customer-installed software.
Page 203: Nac 2 New Installation
6-2 New software installations NAC 2 new installation Perform a NAC 2 new installation if your company has never used a NAC product. Follow Procedure 6-1 if your system has customer-installed software. Use Procedure 6-2 if your system has factory-installed software.
Page 204 Procedure 6-1 New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Before beginning the software installation, ensure that the MVME167-34 card has been configured correctly. Refer to the “Hardware installation” chapter. Make sure the power is turned off.
Page 205 6-4 New software installations Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Wait for the tape to rewind. The tape drive light turns off when the tape is rewound. At the previous prompt, enter bo 0,40 followed by {RETURN}.
Page 206 Note: The previous message indicates that pressing the {~} key causes a system interruption which terminates the current process. The {DEL} key deletes and back- spaces one character. –––> Do you wish to verify the identity of the NAC Application Tape (y/n) ? Network Administration Center (NAC) Installation Guide Product release 2...
Page 207 Step 14. If you want to verify the customer purchasable options on the application tape, enter y, followed by {RETURN}. Please remove the OS tape from the tape drive and insert the NAC Application tape. Remove the OS tape and insert the application tape.
Page 208 If the OS tape is in the tape drive and the tape drive light is off, enter y, followed by {RETURN}. The system displays the hardware configuration. NAC has detected that you are running the following hardware configuration: Memory Hard Disk...
Page 209 NAC Installation/Upgrade Restart Menu. The NAC Installation/Upgrade Restart Menu -–––––––––––––––––––––––––––––––––––––––– Restart NAC 2 installation from one of the following stages: From the Beginning Just Before Copying OS Files to Hard Disk Just Before Copying NAC Application Files to Hard Disk Just Before Booting From Hard Disk ––>...
Page 210 If you want to restart the installation just before the NAC system boots from the hard disk, enter 4, followed by {RETURN}. The system displays the following message.
Page 211 6-10 New software installations Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response If you want to begin the installation, enter y, followed by {RETURN}. The system continues. ***> Beginning installation/upgrade (TIME) ***>...
Page 212 Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response If you chose reentry point 4 in Step 18 (to restart the installation just before booting from the hard disk for the first time), the system displays the following messages.
Page 213 6-12 New software installations Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response ***> Formatting root file system’s disk drive (TIME) This will take about 30 minutes... ***> Writing slice table to /dev/rdsk/m167_00s7 (TIME) ***>...
Page 214 ***> Installing NAC–specific configuration files (TIME) ***> Setting permissions on installation disk’s root directory (TIME) ********************************************************************* * Stage 3 — Copying NAC Application Files to Hard Disk ********************************************************************* Please remove the OS tape from the tape drive and put in the NAC 2 Application tape.
Page 215 6-14 New software installations Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Remove the OS tape from the tape drive and insert the application tape. Wait for the tape to rewind. The tape drive light turns off when the tape is rewound.
Page 216 Local Memory Found =02000000 (&33554432) MPU Clock Speed =33Mhz Network Administration Center (NAC) Installation Guide Product release 2 The NAC 2 product has been installed on the hard disk. You may now remove the tape from the tape drive. ***************************...
Page 217 6-16 New software installations Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Autoboot in progress... To abort hit <BREAK> Booting from: VME167, Controller 0, Drive 0 Loading: Operating System Volume: $00000000 IPL loaded at: $001F0000 VME Disk IPL Version 52.2...
Page 218 Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Default boot sequencing continuing... The system is coming up. Please wait. Node name set to NAC00 mount –f S51K /dev/usr /usr Checking for system dump...
Page 219 6-18 New software installations Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response If you selected reentry point 1, 2 or 3, the following prompt appears. Your current language options are: If you selected reentry point 4, the following prompt appears.
Page 220 Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Configure NAC System Use up and down arrows to move among menu items and press You must enter your system’s port assignments, define your network definitions, and verify the system parameters before exiting this screen.
Page 221 Installer’s action and system’s response The NAC Communication Port Assignment screen appears. This screen is only an example of a NAC 2 system with no ports assigned. A NAC 2 system can have 8, 16, 24, 32 or 40 ports.
Page 222 Input/Output panel. The connection letter refers to the specific port to which the devices are attached. A NAC 2 system can have 8, 16, 24, 32 or 40 ports. If your system has more than 16 ports, all of the ports cannot be viewed on a single screen.
Page 223 {RETURN}. If a device name is ghosted, it cannot be selected. Links The Device field can use two different links to connect NAC to a Meridian MAX node: Network Link and Remote Supervisor Login. 553-4011-110 Standard 1.0 November 1994 Available Ports: # 1.Network Link...
Page 224 Supervisor Login link can be assigned on the NAC for each Meridian MAX node. Alternatively, one or more modem connection Remote Supervisor Login links can be assigned on the NAC to access any of a group of Meridian MAX nodes. A combination of the two methods can be used.
Page 225 Press {PF3} to edit the Name/Comment field for a specific device. When you have finished entering information on the NAC Communication Port Assignment screen, press {PF1} and select the “Save changes and exit” command.
Page 226 For example, if the Network Link between the Toronto node and the NAC uses dial-up modems running at 9600 baud, then 9600 should be selected for the baud field for that specific link.
Page 227 Meridian MAX node in question, meaning the node is two hours behind the NAC. To enter the Time Zone, press {PF3}, type the Time Zone number and press {PF3} again or type the Time Zone number and press {RETURN}.
Page 228 {PF3} again or type the Remote Login Directory Number and press {RETURN}. Ntwk Link This field controls the visibility of the node to the NAC system. When this field is set to Disabled, the node does not provide information to the NAC, supervisor messages cannot be transmitted to and from the Meridian MAX node, remote printing cannot occur, and remote supervisor logins to the Meridian MAX node are prohibited.
Page 229 Rate Customer Name The Customer Name field allows you to record the NAC customer name. This name appears on the network reports and display screens. Typically the customer name is the same as your company’s name. To enter the Customer Name, press {PF3}, type the Customer Name and press {PF3} again or type the Customer Name and press {RETURN}.
Page 230 Default Language, press {PF2}. Move the cursor to the selection and press {RETURN} or enter the selection number and press {RETURN}. Note: The default language can be changed once the NAC system is running by using the Language Options screen. Refer to the NAC 2 Supervisor’s User Guide (P0724352), “Parameter administration”...
Page 231 Installer’s action and system’s response NAC to Node Login Password The NAC to Node Login Password field defines the password used by the system to bring up the Network Link between the NAC and its Meridian MAX nodes. If this...
Page 232 Procedure 6-1 (continued) New installation of the NAC 2 system: customer-installed software Step Installer’s action and system’s response Setting the time to Thu Jun 22 12:00 1989 for Training mode. Loading System Language Strings... Loading System Language Strings completed. NAC release 02.xx...
Page 233 Before logging in, ensure that the installation was successful. Review the NAC error log for any fatal messages. Log in as maint and refer to the NAC 2 System Administration and Maintenance Guide (NTP 553 running” chapter, “Diagnostics” section, “View NAC error log” subsection for more information.
Page 234: Factory-Installed Software
Factory-installed software To perform the following procedure, you need the NAC 2 application tape and the generic operating system tape. Procedure 6-2 New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response Before beginning the software installation, ensure that the MVME167-34 card has been configured correctly.
Page 235: 553-4011-110 Standard 1.0 November 1994
6-34 New software installations Procedure 6-2 (continued) New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response MPU Clock Speed =33Mhz Autoboot in progress... To abort hit <BREAK> Booting from: VME167, Controller 0, Device 0...
Page 236 Procedure 6-2 (continued) New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response 167 SCSI configuration Device Addr Vers –––––– –––– –––– –––––––– ––––––– Disk 0002 8988... Tape 0001 RV J... Enter <CR> to pause in a single user shell before init.
Page 237 6-36 New software installations Procedure 6-2 (continued) New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response Please login as precut for more details. The system is ready. Console login: Using the Maintenance console, login as maint.
Page 238 Procedure 6-2 (continued) New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response The system displays the NAC Maintenance and Administration Menu that appears while the system is active. NAC Maintenance and Administration View NAC Options...
Page 239 Procedure 6-2 (continued) New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response The system displays the NAC Maintenance and Administration Menu that appears while the system is inactive. NAC Maintenance and Administration View NAC Options Restart &...
Page 240 Step Installer’s action and system’s response Enter v, followed by {RETURN}, for the View NAC Options screen. Then enter c, followed by {RETURN}, to view the NAC options already selected for your site. The system displays the NAC Options screen. This screen is a sample.
Page 241 6-40 New software installations Procedure 6-2 (continued) New installation of the NAC 2 system: factory-installed software Step Installer’s action and system’s response Enter r and press {RETURN}. The system displays the Restart & Power Down System Utilities submenu. Press r,s,i,h,or q and ENTER: Enter r, followed by {RETURN}.
Page 242 Enter y, followed by {RETURN}. The system displays the following message: The operating system will shut down and restart, and then NAC will restart. Please wait for system to reboot. The system displays a number of messages as it shuts down. After shutdown the system automatically reboots.
Page 243 Step Installer’s action and system’s response Log in as precut to view the NAC Training Mode screen. Refer to the “Operating modes” chapter, “Training mode” section for further instruc- tions on how to transfer from Training mode to Precutover mode.
Page 244: Loading A New Software Release
Use Procedure 7-1 if you need to load a new NAC 2 software release onto an existing NAC 2 system. Note: These procedures should not be used if the new software’s options are different from the existing options, or if you are upgrading to a new release number, that is Release 1 to Release 2.
Page 245: Loading A New Release Of Nac 2 Software
7-2 Loading a new software release Loading a new release of NAC 2 software To load new software onto an existing NAC system, follow Procedure 7-1. Procedure 7-1 Load New Software Release for a NAC 2 system Step Installer’s action and system’s response Using the maintenance console, login as maint.
Page 246 The system displays the following: NAC terminating... cron aborted: SIGTERM Signal forces mapa_logger termination The system shows the system-inactive NAC Maintenance and Administration menu. Network Administration Center (NAC) Installation Guide Product release 2 Configuration of NAC System (View Only) —continued—...
Page 247 Configure NAC System Help Logout Press v,r,b,d,p,c,h,or l and ENTER: Enter b, followed by {RETURN}, to go to the Backup and Restore Utilities menu. The system displays the NAC Backup and Restore Utilities menu. 553-4011-110 Standard 1.0 November 1994 —continued—...
Page 248 Enter l, followed by {RETURN}, to run the Load New Software Release utility. The system displays the following messages. Upgrade of NAC software requires that you save the current contents of the hard disk on a tape. Do you want to save the contents of the hard disk on a tape (y/n)? If you have just made a backup of the hard disk, enter n, followed by {RETURN}, and go to Step 10.
Page 249 7-6 Loading a new software release Procedure 7-1 (continued) Load New Software Release for a NAC 2 system Step Installer’s action and system’s response The system then displays the following messages. Please insert a blank 600M tape into the tape drive.
Page 250 Did you put in the cassette tape? Please enter yes/no/quit–to abort (y/n/q): Insert the cassette tape which contains the new NAC application software into the module’s tape drive. Enter y, followed by {RETURN}.
Page 251 Upgrade of NAC 2 software has been completed. Press ENTER to return to menu. Press {RETURN}. The system returns the NAC Backup and Restore Utilities screen. Press b,r,l,h or q and ENTER: 553-4011-110 Standard 1.0 November 1994 NAC Backup and Restore Utilities...
Page 252 Procedure 7-1 (continued) Load New Software Release for a NAC 2 system Step Installer’s action and system’s response Enter q, followed by {RETURN}, to quit the menu and return to the system-inactive Meridian MAX Maintenance and Administration screen. NAC Maintenance and Administration View NAC Options Restart &...
Page 253 7-10 Loading a new software release Procedure 7-1 (continued) Load New Software Release for a NAC 2 system Step Installer’s action and system’s response Press r,s,i,h or q and ENTER: Enter r, followed by {RETURN}, to restart the system. The system clears the screen and displays the following prompt.
Page 254 Enter y, followed by {RETURN}, to confirm that you want to restart the system. The system displays the following messages: The operating system will shut down and restart, and then NAC will restart. Please wait for the system to reboot.
Page 255 7-12 Loading a new software release Procedure 7-1 (continued) Load New Software Release for a NAC 2 system Step Installer’s action and system’s response Copyright Motorola Inc. 1989 – 1993 All Rights Reserved VME167 Monitor/Debugger Release 1.5 – 02/14/93 COLD START Local Memory Found =01000000 (&33554432)
Page 256 Procedure 7-1 (continued) Load New Software Release for a NAC 2 system Step Installer’s action and system’s response 167 SCSI configuration Device Addr Vers –––––– –––– –––– –––––––– ––––––– Disk 0002 8988... Tape 0001 RV J... Enter <CR> to pause in a single user shell before init.
Page 257 7-14 Loading a new software release Procedure 7-1 (continued) Load New Software Release for a NAC 2 system Step Installer’s action and system’s response The system displays the following prompts. The current Date and Time are ‘Mon Feb 14 12:42:00 STD 1994’...
Page 258: Software Reinstallations And Upgrades
Software reinstallations and upgrades Before starting any upgrade, verify that the system is performing properly. Check the NAC error log and the UNIX system log (when appropriate) to verify that midnight backups are successfully completed. Schedule an upgrade to be completed before 11:30 p.m. or started after 1:00 a.m. so that the regular NAC midnight routines are executed properly.
Page 259: Software Reinstallation Or Upgrade For A Nac 2 System
Software reinstallation or upgrade for a NAC 2 system Use Procedure 8-1 if you want to perform one of the following procedures. Reinstallation: You are currently running NAC 2 and want to install new NAC 2 system software to incorporate operating system and database changes.
Page 260 Restore Utilities. From the Backup and Restore Utilities submenu, choose option b again, Backup Customer Data to Tape to save the NAC 2 system data to the tape. This ensures that all current NAC data is backed up. This procedure uses cassette tapes. Care must be taken to avoid damaging the tape, as its fragility can result in tape errors during the installation procedure.
Page 261 8-4 Software reinstallations and upgrades Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response Power up the module. The power switch is located on the left-hand side of the AEM module. The upper switch controls the power for the application module in the left side of the AEM, while the lower switch controls the power for the right side.
Page 262 Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response IPL Loaded at: $001F0000 MVMETAPE IPL Version 1.0 There is a one to two minute delay before the system continues with the following.
Page 263 The {DEL} key deletes and back- spaces one character. –––> Do you wish to verify the identity of the NAC Application Tape (y/n) ? If you do not wish to verify the options, enter n, followed by {RETURN}, and go to Step 18.
Page 264 Wait for the tape to rewind. The tape drive light turns off when the tape is rewound. –––> Is the NAC Application tape in the tape drive (y/n/q) ? If the application tape is in the tape drive and the tape drive light is off, enter y, followed by {RETURN}.
Page 265 Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response The system displays the hardware configuration. NAC has detected that you are running the following hardware configuration: Memory Hard Disk Tape Drive If this configuration does not match your configuration, please type “n”...
Page 266 Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response If you are performing a reinstallation or an installation upgrade, enter 2, followed by {RETURN}. The system displays the following message. Will perform an Installation Upgrade.
Page 267 If you want to restart the installation from the beginning, enter 1, followed by {RE- TURN}. The system displays the following message. You have chosen to start the NAC 2 install/upgrade from the beginning. If you want to restart the installation just before the OS files are copied to the hard disk, enter 2, followed by {RETURN}.
Page 268 If you want to restart the installation just before the NAC system boots from the hard disk, enter 4, followed by {RETURN}. The system displays the following message.
Page 269 8-12 Software reinstallations and upgrades Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response If you are performing an application upgrade, or if you chose reentry point 3 in Step 23 (to restart the installation just before copying the application files to the hard disk) the system displays the following messages.
Page 270 Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response ********************************************************************* * Stage 1 — Formatting Hard Disk Drive and Creating Filesystems * ********************************************************************* ***> Formatting root file system’s disk drive (TIME) This will take about 30 minutes...
Page 271 ***> Installing NAC–specific configuration files (TIME) ***> Setting permissions on installation disk’s root directory (TIME) ********************************************************************* * Stage 3 — Copying NAC Application Files to Hard Disk ********************************************************************* Please remove the OS tape from the tape drive and put in the NAC 2 Application tape.
Page 272 Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response Remove the OS tape from the tape drive and insert the application tape. Wait for the tape to rewind. The tape drive light turns off when the tape is rewound.
Page 273 Local Memory Found =02000000 (&33554432) MPU Clock Speed =33Mhz 553-4011-110 Standard 1.0 November 1994 The NAC 2 product has been installed on the hard disk. You may now remove the tape from the tape drive. *************************** **** REBOOT THE SYSTEM **** *************************** —continued—...
Page 274 If you are completing an installation upgrade, the following messages appear. –––> The INSTALLATION UPGRADE process requires you to obtain or create a Customer Data Backup Tape from your previous NAC 2 system. Please insert this backup tape into the internal cassette tape drive now.
Page 275 If you are completing an application upgrade, the following messages appear. –––> The APPLICATION UPGRADE process requires you to obtain or create a Customer Data Backup Tape from your previous NAC 2 system. Please insert this backup tape into the internal cassette tape drive now.
Page 276 Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response The system continues. 167 SCSI configuration Device Addr Vers –––––– –––– –––– –––––––– ––––––– Disk 0002 8988... Tape 0001 RV J... This configuration is only an example. Your system may differ.
Page 277 8-20 Software reinstallations and upgrades Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response ***> Finished configuring port devices. (TIME) The following message only appears if you are using reentry points 2, 3, or 4.
Page 278 Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response Extracting old NAC 2 system data files... Loading more NAC 2 system data files... Data files loaded Go to Step 38. ***> Creating the SYSTEM database — please wait... (TIME) SYSTEM database created.
Page 279 8-22 Software reinstallations and upgrades Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response Configure NAC System Use up and down arrows to move among menu items and press You must enter your system’s port assignments, define your network definitions, and verify the system parameters before exiting this screen.
Page 280 Installer’s action and system’s response The NAC Communication Port Assignment screen appears. This screen is only an example of a NAC 2 system with no ports assigned. A NAC 2 system can have 8, 16, 24, 32 or 40 ports.
Page 281 Input/Output panel. The connection letter refers to the specific port to which the devices are attached. A NAC 2 system can have 8, 16, 24, 32 or 40 ports. If your system has more than 16 ports, all of the ports cannot be viewed on a single screen.
Page 282 If an device name is ghosted, it cannot be selected. Links The Device field can use two different links to connect NAC to a Meridian MAX node: Network Link and Remote Supervisor Login. Network Administration Center (NAC) Installation Guide Product release 2...
Page 283 NAC for each Meridian MAX node. Alternatively, one or more modem connection Remote Supervisor Login links can be assigned on the NAC to access any of a group of Meridian MAX nodes. A combination of the two methods can be used.
Page 284 Press {PF3} to edit the Name/Comment field for a specific device. When you have finished entering information on the NAC Communication Port Assignment screen, press {PF1} and select the “Save changes and exit” command.
Page 285 For example, if the Network Link between the Toronto node and the NAC uses dial-up modems running at 9600 baud, then 9600 should be selected for the baud field for that specific link.
Page 286 Meridian MAX node in question, meaning the node is two hours behind the NAC. To enter the Time Zone, press {PF3}, type the Time Zone number and press {PF3} again or type the Time Zone number and press {RETURN}.
Page 287 {PF3} again or type the Remote Login Directory Number and press {RETURN}. Ntwk Link This field controls the visibility of the node to the NAC system. When this field is set to Disabled, the node does not provide information to the NAC, supervisor messages cannot be transmitted to and from the Meridian MAX node, remote printing cannot occur, and remote supervisor logins to the Meridian MAX node are prohibited.
Page 288 Rate Customer Name The Customer Name field allows you to record the NAC customer name. This name appears on the network reports and display screens. Typically the customer name is the same as your company’s name. To enter the Customer Name, press {PF3}, type the Customer Name and press {PF3} again or type the Customer Name and press {RETURN}.
Page 289 Default Language, press {PF2}. Move the cursor to the selection and press {RETURN} or enter the selection number and press {RETURN}. Note: The default language can be changed once the NAC system is running by using the Language Options screen. Refer to the NAC 2 Supervisor’s User Guide (P0724352), “Parameter administration”...
Page 290 Installer’s action and system’s response NAC to Node Login Password The NAC to Node Login Password field defines the password used by the system to bring up the Network Link between the NAC and its Meridian MAX nodes. If this...
Page 291 8-34 Software reinstallations and upgrades Procedure 8-1 (continued) Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response The following prompt appears only when you are using Reentry point 4 and switch to a new installation.
Page 292 Software reinstallation or upgrade to a NAC 2 system Step Installer’s action and system’s response Before logging in, ensure that the installation was successful. Review the NAC error log for any fatal messages. Login as maint and refer to the NAC 2 System Administration and Maintenance Guide (NTP 553-4011-510), “Maintenance and administration programs: System...
Page 293: Platform Upgrades
Platform upgrades If you are currently running a NAC 1 system and want to upgrade your operation to a NAC 2 system, a platform upgrade is needed. Use Procedure 9-1 to complete a platform upgrade from NAC 1 to NAC 2.
Page 294 Platform upgrade from a NAC 1 system to a NAC 2 system Use Procedure 9-1 if you are upgrading your NAC 1 system to a NAC 2 system. After the system reboot following the operating system and application tape installation, you can follow one of two paths in this procedure.
Page 295: Platform Upgrade From A Nac 1 System To A Nac 2 System
SCSI port with a SCSI terminator-connector attached to it. If your NAC module is in the second module of the AEM, go to Step 11. If your NAC module is in the first module of the AEM, go to Step 9.
Page 296 One increases the number, while the other decreases it. Press these buttons until the number five (5) appears in the window. Insert the NAC 1 customer data backup tape into the tape drive. Slide the tape drive latch shut.
Page 297 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response The system displays the copyright and hardware configuration information. Your sys- tem information may differ. Copyright Motorola Inc. 1988 – 1993, All Rights Reserved MVME167 Debugger/Diagnostics Release Version 1.5 –...
Page 298 9-6 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response ********************************************************************* ********************************************************************* Copyright (c) 1984–1993 Motorola Inc. All rights reserved. INIT: SINGLE USER MODE erase = # kill = @ Intr = DEL quit = ^| Note: The previous message indicates that pressing the backspace key causes a system interruption which terminates the current process.
Page 299 The {DEL} key deletes and back- spaces one character. –––> Do you wish to verify the identity of the NAC Application Tape (y/n) ? If you do not wish to verify the options, enter n, followed by {RETURN}, and skip to Step 29.
Page 300 9-8 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response Remove the OS tape and insert the application tape. Wait for the tape to rewind. The tape drive light turns off when the tape is rewound.
Page 301 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response The system displays the hardware configuration. NAC has detected that you are running the following hardware configuration: Memory Hard Disk...
Page 302 9-10 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response If you do not want to restart a previously aborted installation, enter n, followed by {RETURN}. Go to Step 34. If you want to restart a previously aborted installation, enter y, followed by {RETURN}.
Page 303 If you want to restart the installation just before the NAC system boots from the hard disk, enter 4, followed by {RETURN}. The system displays the following message.
Page 304 9-12 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response If you want to begin the installation, enter y, followed by {RETURN}. The system continues. ***> Beginning installation/upgrade (TIME) ***>...
Page 305 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response If you chose reentry point 4 in Step 33 (to restart the installation just before booting from the hard disk for the first time), the system displays the following messages.
Page 306 9-14 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response ***> Formatting root file system’s disk drive (TIME) This will take about 30 to 60 minutes...
Page 307 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response ***> Mounting usr file system as /root/usr (TIME) ***> Copying files; this will take from 5 to 15 minutes depending upon your system configuration...
Page 308 9-16 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response Remove the OS tape from the tape drive and insert the application tape. Wait for the tape to rewind. The tape drive light turns off when the tape is rewound.
Page 309 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response * You must REBOOT the system and allow it to autoboot from the hard * * disk. Please power off the system now.
Page 310 9-18 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response Autoboot in progress... To abort hit <BREAK> Booting from: VME167, Controller 0, Drive 0 Loading: Operating System...
Page 311 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response If you do not have a backup tape or wish to avoid installing your backup data, enter c, followed by {RETURN}. The system displays the following message.
Page 312 9-20 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response Expreserve notification performed. Downloading MVME332XT Line Disciplines. Error logging started. OSM Logging Started. ***> Configuring port devices. (TIME) ***>...
Page 313 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response ***> Performing byte swapping on the databases... (TIME) Byte swapping can take from 1 to 2 minutes, depending on the sizes of the databases...
Page 314 9-22 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response This language selection is only an example. The languages installed in your system may differ. If you selected reentry point 1, 2 or 3, the following prompt appears.
Page 315 Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response This language selection is only an example. The languages installed in your system may differ. Your language options are already selected:...
Page 316 Installer’s action and system’s response The NAC Communication Port Assignment screen appears. This screen is only an example of a NAC 2 system with no ports assigned. A NAC 2 system can have 8, 16, 24, 32 or 40 ports.
Page 317 Input/Output panel. The connection letter refers to the specific port to which the devices are attached. A NAC 2 system can have 8, 16, 24, 32 or 40 ports. If your system has more than 16 ports, all of the ports cannot be viewed on a single screen.
Page 318 {RETURN}. If a device name is ghosted, it cannot be selected. Links The Device field can use two different links to connect NAC to a Meridian MAX node: Network Link and Remote Supervisor Login. 553-4011-110 Standard 1.0 November 1994 Available Ports: # 1.Network Link...
Page 319 Meridian MAX node as a remote supervisor. A direct connection Remote Login link can be assigned on the NAC for each Meridian MAX node. Alternatively, one or more modem connection Remote Supervisor Login links can be assigned on the NAC to access any of a group of Meridian MAX nodes.
Page 320 9-28 Platform upgrades Procedure 9-1 (continued) Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response Connect A connection type for each device must be entered in the Connect field. This entry must be selected from one of the following choices that appear in a pop-up.
Page 321 For example, if the Network Link between the Toronto node and the NAC uses dial-up modems running at 9600 baud, then 9600 should be selected for the baud field for that specific link.
Page 322 Meridian MAX node in question, meaning the node is two hours behind the NAC. To enter the Time Zone, press {PF3}, type the Time Zone number and press {PF3} again or type the Time Zone number and press {RETURN}.
Page 323 {PF3} again or type the Remote Login Directory Number and press {RETURN}. Ntwk Link This field controls the visibility of the node to the NAC system. When this field is set to Disabled, the node does not provide information to the NAC, supervisor messages cannot be transmitted to and from the Meridian MAX node, remote printing cannot occur, and remote supervisor logins to the Meridian MAX node are prohibited.
Page 324 Rate Customer Name The Customer Name field allows you to record the NAC customer name. This name appears on the network reports and display screens. Typically the customer name is the same as your company’s name. To enter the Customer Name, press {PF3}, type the Customer Name and press {PF3} again or type the Customer Name and press {RETURN}.
Page 325 Default Language, press {PF2}. Move the cursor to the selection and press {RETURN} or enter the selection number and press {RETURN}. Note: The default language can be changed once the NAC system is running by using the Language Options screen. Refer to the NAC 2 Supervisor’s User Guide (P0724352), “Parameter administration”...
Page 326 Installer’s action and system’s response NAC to Node Login Password The NAC to Node Login Password field defines the password used by the system to bring up the Network Link between the NAC and its Meridian MAX nodes. If this...
Page 327 The system is ready. Console Login: Login as maint. Shut down and power down the system. Refer to the “NAC power-down procedure” chapter. Unhook the SCSI terminal cable from the NAC external SCSI port. Replace the terminator-connector on the NAC external SCSI port.
Page 328 Platform upgrade from a NAC 1 system to a NAC 2 system Step Installer’s action and system’s response Before logging in, ensure that the installation was successful. Review the NAC error log for any fatal messages. Login as maint and refer to the NAC 2 System Administration and Maintenance Guide (NTP 553-4011-510), “Maintenance and administration programs: System...
Page 329: Operating Modes
Description of software installation procedures Switching the default language Switching from Training mode to Precutover mode for NAC 2 systems Switching from Precutover mode to Product mode for NAC 2 systems Network Administration Center (NAC) Installation Guide Product release 2...
Page 330: Training Mode
{ENTER}. The system saves your changes and returns you to the main menu. Return to the main menu and log out of the NAC system. The next time you log into the system the new default language you chose is used by the system.
Page 331: Training Mode
When the system is booted up after the hardware installation (and software if your system has customer-installed software), a number of operational messages, the release number, and a NAC Training mode message is displayed. When training ends, enter precut at the maintenance terminal login prompt and the menu shown in Figure 10-1 is displayed.
Page 332 {h}, followed by {RETURN}. The supervisor workstations can be used in the Training mode as soon as NAC starts up. You have to select and/or define the workstation type before using the workstation for the first time after a system restart. Workstations remain active until either the system is shut down or Precutover mode is selected from the system console.
Page 333: Precutover Mode
Procedure 10-2. In the Precutover mode, the database can be built in preparation for actual NAC operations. Once the system database is set up, you can convert to the Product mode. This is the operational mode where typical NAC operations occur.
Page 334: Training Mode To Precutover Mode
Follow Procedure 10-2 if you are switching from Training mode to Precutover mode on a NAC 2 system. Procedure 10-2 Switching from Training mode to Precutover mode for NAC 2 systems Step Installer’s action and system’s response Enter precut as the login ID when you log into the maintenance terminal.
Page 335 The system continues. WARNING: Going to Pre-Cutover mode is an irreversible process. You can only return to training mode by reloading the NAC software from the original tape. All supervisor activity should be halted before doing this transition. Press ‘y’ and ENTER to confirm transition into Pre–Cutover mode.
Page 336 10-8 Operating modes Procedure 10-2 (continued) Switching from Training mode to Precutover mode for NAC 2 systems Step Installer’s action and system’s response Enter y, followed by {RETURN}. The system continues. NAC terminating... cron aborted: SIGTERM cron aborted: SIGTERM Signal forces mapa_logger termination ***>...
Page 337 Procedure 10-2 (continued) Switching from Training mode to Precutover mode for NAC 2 systems Step Installer’s action and system’s response Configure NAC System Use up and down arrows to move among menu items and press You must enter your system’s port assignments, define your network definitions, and verify the system parameters before exiting this screen.
Page 338 Installer’s action and system’s response The NAC Communication Port Assignment screen appears. This screen is only an example of a NAC 2 system with no ports assigned. A NAC 2 system can have 8, 16, 24, 32 or 40 ports.
Page 339 Input/Output panel. The connection letter refers to the specific port to which the devices are attached. A NAC 2 system can have 8, 16, 24, 32 or 40 ports. If your system has more than 16 ports, all of the ports cannot be viewed on a single screen.
Page 340 {RETURN}. If an device name is ghosted, it cannot be selected. Links The Device field can use two different links to connect NAC to a Meridian MAX node: Network Link and Remote Supervisor Login. 553-4011-110 Standard 1.0 November 1994 Available Ports: # 1.Network Link...
Page 341 NAC for each Meridian MAX node. Alternatively, one or more modem connection Remote Supervisor Login links can be assigned on the NAC to access any of a group of Meridian MAX nodes. A combination of the two methods can be used.
Page 342 Press {PF3} to edit the Name/Comment field for a specific device. When you have finished entering information on the NAC 2 Communication Port Assignment screen, press {PF1} and select the “Save changes and exit” command.
Page 343 For example, if the Network Link between the Toronto node and the NAC uses dial-up modems running at 9600 baud, then 9600 should be selected for the baud field for that specific Link.
Page 344 Meridian MAX node in question, meaning the node is two hours behind the NAC. To enter the Time Zone, press {PF3}, type the Time Zone number and press {PF3} again or type the Time Zone number and press {RETURN}.
Page 345 Installer’s action and system’s response Remote Login Port The specific port on the NAC system that is connected to a Meridian MAX node. This connection allows the user to log in to Meridian MAX from the NAC as a Remote Supervisor.
Page 346 Rate Customer Name The Customer Name field allows you to record the NAC customer name. This name appears on the network reports and display screens. Typically the customer name is the same as your company’s name. To enter the Customer Name, press {PF3}, type the Customer Name and press {PF3} again or type the Customer Name and press {RETURN}.
Page 347 Default Language, press {PF2}. Move the cursor to the selection and press {RETURN} or enter the selection number and press {RETURN}. Note: The default language can be changed once the NAC system is running by using the Language Options screen. Refer to the NAC 2 Supervisor’s User Guide (P0724352), “Parameter administration”...
Page 348 Installer’s action and system’s response NAC to Node Login Password The NAC to Node Login Password field defines the password used by the system to bring up the Network Link between the NAC and its Meridian MAX nodes. If this...
Page 349 Procedure 10-2 (continued) Switching from Training mode to Precutover mode for NAC 2 systems Step Installer’s action and system’s response Loading data files for precut mode... Data files loaded ***> Creating USER LANGUAGE database – please wait (TIME) USER LANGUAGE database created.
Page 350 10-22 Operating modes Procedure 10-2 (continued) Switching from Training mode to Precutover mode for NAC 2 systems Step Installer’s action and system’s response Local Memory Found =02000000 (&33554432) MPU Clock Speed =33Mhz Autoboot in progress... To abort hit <BREAK> Booting from: VME167, Controller 0, Device 0...
Page 351 Procedure 10-2 (continued) Switching from Training mode to Precutover mode for NAC 2 systems Step Installer’s action and system’s response Enter <CR> to pause in a single user shell before init. Default boot sequence continuing... The system is coming up. Please wait.
Page 352: Precutover Mode To Product Mode
When you login as precut, the Precutover Mode menu screen is displayed (see Fig- ure 10-2). Refer to Procedure 10-3, “Switching from Precutover mode to Product mode for NAC 2 systems” for instructions on how to transfer from the Precutover mode to the Prod- uct mode.
Page 353: Product Mode
This is done by logging in at a supervisor’s workstation, initially as Supervisor 0. Refer to the “Parameter Administration” chapter of the NAC 2 Supervisor’s User Guide (P0724352) for further information. When the system is booted up after the transition from Training mode to Precutover mode is completed, log into the maintenance terminal as “precut”, enter the password provided by your NT representative or...
Page 354 10-26 Operating modes Before switching to Product mode, ensure that the following are ready: Supervisors and agents are trained and ready to use the NAC system. All workstations are logged out. NAC database is set up correctly. The Product mode is the normal mode for operation. Once in Product mode, your NAC system is completely installed.
Page 355: Precutover Mode To Product Mode
Follow Procedure 10-3 if you are switching from Precutover mode to Product mode on a NAC 2 system. Procedure 10-3 Switching from Precutover mode to Product mode for NAC 2 systems Step Installer’s action and system’s response Enter precut as the login ID when you log into the maintenance terminal.
Page 356 The system continues. WARNING: Cutting over to Product mode is an irreversible process. You can only return to training/pre-cutover mode by reloading the NAC software from the original tape. All supervisor activity should be halted before doing this transition. Press ‘y’ and ENTER to confirm cutting over to Product mode.
Page 357 Procedure 10-3 (continued) Switching from Precutover mode to Product mode for NAC 2 systems Step Installer’s action and system’s response Enter y, followed by {RETURN}, to convert to Product mode. The system displays: NAC terminating... cron aborted: SIGTERM cron aborted: SIGTERM...
Page 358 10-30 Operating modes Procedure 10-3 (continued) Switching from Precutover mode to Product mode for NAC 2 systems Step Installer’s action and system’s response Booting from: VME167, Controller 0, Device 0 Loading: Operating System Volume: $00000000 IPL loaded at: $001F0000 VME Disk IPL Version 52.2...
Page 359 Procedure 10-3 (continued) Switching from Precutover mode to Product mode for NAC 2 systems Step Installer’s action and system’s response mount –f S51K /dev/usr /usr Checking for system dump... Expreserve notification performed. Downloading MVME332XT Line Discipline. Error logging started. OSM logging started.
Page 360 10-32 Operating modes Procedure 10-3 (continued) Switching from Precutover mode to Product mode for NAC 2 systems Step Installer’s action and system’s response Loading System Language Strings... Loading System Language Strings completed. Starting NAC OSM Logger, Please wait... OSM Logging stopped.
Page 361: Nac Power-Down Procedure
NAC power-down procedure The NAC system is designed to work most effectively when the system is left on at all times. If there is no overruling, site-specific reason for turning off the NAC system, it is recommended that the system be left on.
Page 362: Nac Installation Checklist
NAC installation checklist This checklist provides you with a handy reference for installing your NAC system. All items on the checklist correspond to sections and chapters of this document. Be certain you read the document before proceeding with any installation procedure.
Page 363: Software Installation
12-2 NAC installation checklist Install the printers. Ensure that the settings are correct. For more information, refer to the “Printers” section of the “Peripheral devices” chapter. Printer(s) installed ? Install the workstations. Ensure that the PCs are configured and VDTs are set up.
Page 364: Operating Modes
Make sure that you insert a backup tape into the tape drive. For more information, refer to the “Software installation overview” chapter, “Backups” section . Backup tape inserted ? Network Administration Center (NAC) Installation Guide Product release 2 NAC installation checklist _______________________ _______________________...
Page 365: Field Replaceable Parts
Field replaceable parts Field replaceable parts for a NAC 2 system are listed in Table 13-1. Table 13-1 Recommended spare parts for NAC Application Module Name used in document MVME167–34 CPU MVME332-XT 8 Channel Asynchronous Board MVME712M Transition Card Transition Card for MVME332-XT Board 1.2 GB Disk Drive and 600 MB Tape Drive Unit...
Page 366 13-2 Field replaceable parts The part numbers for interconnect AM cables are listed in Table 13-2. The part numbers for external AM cables are listed in Table 13-3. Table 13-2 Interconnect cables and part numbers for Application Module (AM) ENG Code NT7D47DA Carries input/output between the MVME712M...
Page 367 NT7D61AF NAC 2 system console NT7D61AL (with A0351509 gender NT7D61AT changer) NT7D61AV Network Administration Center (NAC) Installation Guide Product release 2 Field replaceable parts Cable and connector style DB-25 (male) connector to DB-25 (male) connector DB-25 (male) connector to DB-25 (female) connector...
Page 368 ENG code NT8D96AE Carries input/output between the input/output connector panel and the peripheral devices connected to the NAC 2 NT7D99AA Connects as input/output between NAC 2 and dial-up modem, as well as, NAC 2 and LDS modem 553-4011-110 Standard 1.0 November 1994...
Page 369: Nac Time Change Procedure
NAC time change procedure There are cases where the NAC system time must be changed, such as daylight savings time or the time being set incorrectly. If you want to change the time on the NAC, follow these steps: Display the NAC Maintenance and Administration main menu (system running mode).
Page 370 14-2 NAC time change procedure Enter the new time and date in the format mmddhhmmyy. This represents the month, day, hour, minutes and year. For example, enter 0131153095 . After the time and date are entered, they are displayed on the screen.
Page 371 Meridian, Meridian MAX, Meridian MAX - IPE, ACD, ACD-MAX, NAC, Meridian 1, and SL-1, are trademarks of Northern Telecom. Compaq is a trademark of Compaq Computer Corporation. DEC, VT220 and VT420 are trademarks of Digital Equipment Corporation.

Northern Telecom NAC Installation Manual

About this Document

Introduction

Site Preparation

Hardware Installation

Peripheral Devices

Software Installation Overview

New Software Installations

Loading a New Software Release

Software Reinstallations and Upgrades

Platform Upgrades

Operating Modes

NAC Power-Down Procedure

NAC Installation Checklist

Field Replaceable Parts

NAC Time Change Procedure

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Northern Telecom NAC

Summary of Contents for Northern Telecom NAC

Table of Contents
