9-30 Platform upgrades
Procedure 9-1 (continued)
Platform upgrade from a NAC 1 system to a NAC 2 system
Step Installer's action and system's response
Note:
You cannot have both a remote login port and a remote login directory
number for the same MAX node.
54 Fields
The NAC Network Definition/Installation screen has nine fields:
Node Addr, Node Name, Short Name, Time Zone, Connection Baud, Connection
Port, Remote Login Port, Remote Login Directory Number, and Ntwk Link.
Node Addr
The Node Address (location code) for each Meridian MAX site must be three-digits in
length but 000 to 099 are not considered valid entries. To enter the Node Address,
type in the three-digit address and press {RETURN].
Node Name
This field indicates the Node Name for each Meridian MAX site. To enter the Node
Name, press {PF3}, type the Node Name and press {PF3} again or type the Node
Name and press {RETURN}.
Short Name
This field indicates the three character Short Name for each node. Each Short Name
must be unique. To enter the Short Name, press {PF3}, type the Short Name and
press {PF3} again or type the Short Name and press {RETURN}.
Time Zone
This field indicates the time difference between the NAC and the Meridian MAX
node. For example, –2.0 would be the correct response if the NAC system was
situated two time zones to the east of the Meridian MAX node in question, meaning
the node is two hours behind the NAC. To enter the Time Zone, press {PF3}, type
the Time Zone number and press {PF3} again or type the Time Zone number and
press {RETURN}.
Connection Baud
This field indicates the specific baud rate that the Network Link uses to communicate
with the Meridian MAX node. To enter the baud rate, press {PF2}. Move the cursor to
the selection and press {RETURN} or enter the selection number and press
{RETURN}.
