6-24 New software installations
Procedure 6-1 (continued)
New installation of the NAC 2 system: customer-installed software
Step Installer's action and system's response
Connect
A connection type for each device must be entered in the Connect field. This entry
must be selected from one of the following choices that appear in a pop-up.
Depending upon the device assigned, this field may be filled in automatically by the
system. The choices for this field are:
— Direct
— Modem
Baud
Each time you select an Unknown Display, Remote Login, or a Network Link, you
must also select a baud rate. For other devices, the baud rate is assigned
automatically by the system. You must choose from one of the following choices:
— 2400
— 9600
Name/Comment
The Name/Comment field displays the name given to an assigned printer, or
comments made on other devices configured on the system. Press {PF3} to edit the
Name/Comment field for a specific device.
32 When you have finished entering information on the NAC Communication Port
Assignment screen, press {PF1} and select the "Save changes and exit" command.
The communication port assignment information is saved and you are returned to
the Configure NAC System screen.
553-4011-110 Standard 1.0 November 1994
—continued—
