Figure 3-6
Generic input/output connector panel
NT6D51AA transition
card connections
MVME712M transition
card connections
Network Administration Center (NAC) Installation Guide Product release 2
CARD 5 CARD 4 CARD 3 CARD 2
CONN 3 CONN 3 CONN 3 CONN 3
CARD 5 CARD 4 CARD 3 CARD 2
CONN 2 CONN 2 CONN 2 CONN 2
CARD 5 CARD 4 CARD 3 CARD 2
CONN 1 CONN 1 CONN 1 CONN 1
CARD 6 CARD 6 CARD 6
CONN 3 CONN 2 CONN 1
ETHERNET
CARD 1 CARD 1 CARD 1 CARD 1
CONN 4 CONN 3 CONN 2 CONN 1
MODEM
CONS
Hardware installation 3-21
SYS
